ION 9000 Overview

ION 9000 Ports

The ports on the ION 9000 are used as follows:
Ports
AUX Port
USB Port
Controller Ports
Internet/Peering Ports
SFP+ Ports
Fail-to-Wire Ports / Bypass Pairs
ION 9000 Hardware Reference
Descripon
This port is intended for offline access and configuraon
of an uninstalled system.
This port is reserved for future use.
This port is used by the ION device to communicate with
the Prisma SD-WAN controller. By default, controller
ports are DHCP enabled.
These ports are used as internet ports or peering ports.
Ports 9 -12 support 10G SFP+ only, Ports 13 -16 support
1G SFP and 10G SFP+.
4 pairs - ports 1/2, 3/4, 5/6, 7/8.
