- Page 1 MODEL RTA-3992D ASSEMBLY INSTRUCTIONS Thank you for purchasing one of our products. Please read carefully the assembly instructions before the installation. Do not discard this manual or any of the packaging material until the unit has been completely assembled...
- Page 2 RTA-3992D ❸ ❹ ❶ ❷ MAIN PARTS LIST Right leg structure Left leg structure Left ornament panel Right ornament panel ❺ ❻ Main panel Back panel ❽ ❼ Middle shelf Support panels ❾ ⓬ ❿ ⓫ ⓭ Large cup Small accessory...
- Page 3 RTA-3992D MAIN PARTS LAYOUT (FOR REFERENCE): SCREWS LIST: FIGURE SIZE / DESCRIPTION PART 6X40 MM 6X30 MM $)mmnmm 6X55 MM �IIIIIIIIIDIIIIIIDIIIIIIIIIIID 4X14 MM � � ☛ This unit uses cam bolts and locks. The following explains how to use them.
- Page 4 RTA-3992D BEFORE YOU START THE ASSEMBLY, PLEASE READ THE FOLLOWING TIPS AND WARNINGS. ❶ ❼ To avoid misalignments, Do a quick inventory to make sure the package always leave the screws contains all the parts and loose and tighten them until...
- Page 5 RTA-3992D ASSEMBLY STEPS First screw the bolts Ⓐ into the underside holes of the shelf ⑦, then align the cam STEP 1 locks on one of the support panels ⑧ and assemble both panels as shown and as Hardware/Tools: explained in page 3.
- Page 6 RTA-3992D STEP 3 Assemble the left and right ornament panels ③ and ④ to the legs ① and ② using screws Ⓑ from the inside as shown. Hardware/Tools: ���� 6x30mm STEP 4 First screw the bolts Ⓐ into the underside holes of the main panel ⑤, then align the cam locks on the leg structures ①...
- Page 7 RTA-3992D STEP 5 Use screws Ⓓ to assemble to the main panel ⑤ and from underneath, all the holders and accessories ⑨, ⑩, ⑪, ⑫ and ⑬ on the sides of your choice and Hardware/Tools: in the configuration of your preference.
- Page 8 RTA-3992D AFTER THE ASSEMBLY IS DONE, PLEASE READ CAREFULLY THE FOLLOWING CARE AND MAINTENANCE WARNINGS: WEIGHT LIMITS 3.3 Lbs. (1.5 Kg) 110 Lbs. (50 Kg) 3.3 Lbs. (1.5 Kg) 3.3 Lbs. (1.5 Kg) 3.3 Lbs. (1.5 Kg) 3.3 Lbs. (1.5 Kg) 44 Lbs.
