- Page 1 ASSEMBLY INSTRUCTIONS Thanks for purchasing one of our products. Please read carefully the assembly instructions before the installation. Please save this manual for future reference.
- Page 3 ▪ -Top Panel Lower Lower Side Panel Left Lower Side Panel Right Lower Leg Crossbar Leg Crossbar Front Crossbar Stand Panel Lower - Front Leg Left Right & Left x 2 Back Lower - Front Leg Right Top Panel Upper Bottom Panel Upper - Back Leg Left - Back Leg Right...
- Page 4 ▪ PART QTY. ITEM Wooden Pin 10Pcs 6x25mm Wooden Pin 70Pcs 8x25mm Cam Lock & Bolt Sets 10Sets 12mm Cam Lock & 38Sets Bolt Sets 15mm 10Pcs Hole Covers 8Pcs Screw - 3.5 x 15mm 20Pcs Screw - 4 x 30mm 16Pcs Screw - 4 x 38mm Drawer Metal...
- Page 6 - Install all the thick wooden pins (2) into the panels shown in the illustrations, but please make sure to insert them in the correct holes as some holes are intended for cam bolts in subsequent steps. - Install all the thin wooden pins (1) into the panels shown in the illustrations, but please make sure to insert them in the correct holes as some holes are intended for cam bolts in subsequent steps.
- Page 7 ▪ Attach Bolts (4) to all panels as shown, but please make sure to insert them in the correct holes as some holes are intended for the wooden pins in subsequent steps - Attach Bolts (3) to all panels as shown, but please make sure to insert them in the correct holes as some holes are intended for the wooden pins in subsequent steps.
- Page 8 x2 Sets ▪ Assemble the FLAT shaped drawer sliders (9) to the panels (C), (D) and (E) using screws (12) as shown. In panel (E), the sliders attach on both sides of the panel. Set aside the "L" shaped drawer sliders as they will be used until step 19. ▪...
- Page 9 ▪ secure with ▪ Position all the panels as shown in both illustrations, paying close attention to the orientation of legs (K) and (L), and then assemble the panels using Cam Locks (4) as shown.
- Page 10 ▪ secure with 6 Pcs -Attach all Plastic Feet (10) to Leg (I), (J),(K) & (L) as shown. ▪ secure with 8 Pcs (4) as shown.
- Page 11 ▪ secure with ▪ secure with outwards, and its groove faces down) ▪ secure with...
- Page 12 ▪ secure with 4 Pcs Turn the assembled pieces over, and insert back panel (V) with its finished side facing outwards as shown. (The groove on "M" faces down). ▪ Turn the assembled pieces over again, and assemble panel (M) secure with 4 pcs of Cam Locks (4) as shown.
- Page 13 -Assemble drawer back panel (S3), secure with screw (8) as shown. x1 Set Left -Install Handle with screw (11) to panel (S) as shown. bottom of the drawers using screws (6) as shown. -Attach Hole Covers (5) to panels (S1) & Please refer to the illustration for the correct (S2) as shown.
- Page 14 -Assemble drawer side panel (T1) & (T2) to -Insert drawer bottom panel (T4) as shown. drawer front (T), secure with Cam Locks (3) as shown. -Install Handle with screw (11) to panel (T) as shown. Repeat steps 21 to 24 for the second -Assemble drawer back panel (T3), medium drawer.
- Page 15 -Assemble drawer side panel (T1) & (T2) to -Insert drawer bottom panel (U2) drawer front (U), secure with Cam Locks (3) as shown. as shown. - Repeat steps 25 to 28 for the other two -Assemble drawer back panel (U1), small drawers.
- Page 16 secure with -Attach 6 Pcs Hole Covers (5) to panels (G) & (H) as shown. -Place all Drawers into cabinet as shown.
