- Page 1 Installation Guide C2-260 Metal Cabinet Version: 1.0 Due to regular upgrades of systems and products, ZKTeco could not guarantee exact consistency between the actual product and the written information in this manual.
-
Page 2: Control Panel Indicators
2 Control Panel Indicators When the C2-260 is powered on, normally the POWER indicator (red) is lit constantly, the RUN indicator (green) shall flash slowly (indicating the system is normal), and other indicators are all off. COMM indicator (yellow): It flashes when the system is communicating with other devices (e.g., PC). When the indicator is flashing continuously, it indicates data transmission. -
Page 3: Product Dimension
Product Dimension C2-260 Aux485/WR485 C2-260 Metal Cabinet 330.0mm 75.7mm 364.6mm... -
Page 4: Installation Of Panel & Cabinet
Installation of Panel & Cabinet Power Indicator Cable Conduit (Punch Hole for cables) Heat Dissipation Hole C2-260 Panel Aux485 Power Supply MountingHoles MountingHoles We recommend drilling the mounting plate screws into solid wood (i.e. stud/beam). -
Page 5: Internal Wiring Diagram
5 Internal Wiring Diagram C2-260 Power Indicator Power Supply Aux485 12V Battery (Prepared by the user) -
Page 6: Wiring Legend
Wiring Legend Notes: 1. The auxiliary input may connect to infrared body detectors, re alarms, or smoke detectors. 2. The auxiliary output may connect to alarms, cameras or doorbells, etc. 3. PC RS485 indicates the RS485 cable is connected to the DM10/AUX485 through this port. The RS485 Reader port can be connected externally to RS485 reader. - Page 7 7 AUX485 Connection 485A 485B DC12V DC12V AUX485 AUX485 Notes: 1. A C2-260 can connect to maximum two AUX485 modules. 2. Each AUX485 module can connect to maximum four auxiliary devices. 3. Each AUX485 module requires a separate power supply.
- Page 8 RS485 Reader Note: 1. It’s recommended to connect maximum four readers to one C2-260. 2. A single RS485 reader interface can supply a maximum of 750 mA (12V) current. So the entire current consumption should be less than this max value when the readers share the power with the panel.
-
Page 9: Exit Button Connection
Exit Button Connection EXIT K2SExitButton... -
Page 10: Lock Relay Connection
Lock Relay Connection The system supports both Normally Opened Lock and Normally Closed Lock. The NO Lock (Normally Opened when powered) is connected with 'NO' and 'COM' terminals, and the NC Lock (Normally Closed when powered) is connected with 'NC' and 'COM' terminals. The power can be shared with the lock or can be used separately for the lock as shown in the example with NC Lock below.
