MB20-VL Installation Guide

How to install the device?

1.1m

Attach the mounting template sticker to

the wall, and drill holes according to the

mounting paper.

After passing the wires through the wiring hole and

connecting them to the device, and then attach the

device to the back plate from top to bottom.

ZKTECO CO.,LTD. www.zkteco.com

ZKTeco Industrial Park, No. 32, Industrial Road, Tangxia Town, Dongguan, China.

Phone: +86 769 - 82109991

Fix the back plate on the wall using wall

mounting screws.

Fasten the device to the back plate with

a security screw.

Fax: +86 755 - 89602394

Version: 1.0

Table of Contents

Do you have a question about the MB20-VL and is the answer not in the manual?

Page 1 ZKTECO CO.,LTD. www.zkteco.com Copyright © 2021 ZKTECO CO., LTD. All rights reserved. ZKTeco Industrial Park, No. 32, Industrial Road, Tangxia Town, Dongguan, China. Phone: +86 769 - 82109991 Fax: +86 755 - 89602394...
Page 2 Wiring Diagram Door Sensor & Exit Button Connection Door Sensor Exit button Lock Relay Connection Terminals Not sharing power with the lock COM1 Lock FR107 DC12V Sensor NC Lock Button DC5V Power Connection 1. Recommended AC adapter: 2. To share the power with other devices, use an AC adapter with higher current ratings.
