Access Mode
This item defines some special ways that can be used to access IDE hard disks such as LBA (Logical Block
Addressing). Leave this value at Auto and the system will automatically decide the fastest way to access the
hard disk drive.
Press <Esc> to close the IDE device submenu and return to the Standard CMOS Features page.
Floppy Drive A
Select this field to the type of floppy disk drive installed in your system. The choices are:
None
360K, 5.25 in
1. 2M, 5.25 in
720K, 3.5 in
1.44M, 3.5 in
2. 88M, 3.5 in
Note: The None option could be used for diskless workstations.
Floppy 3 Mode Support
Floppy 3 mode refers to 3.5" diskette with a capacity of 1.2 MB. This mode is sometimes used in Japan.
Video
Set this field to the type of graphics card installed in your system. If you are using a BGA or higher resolution
card, choose the EGA/VGA option. The options are:
EGA/VGA
CGA40
CGA80
MONO
Halt On
During the Power-On Self-Test (POST), the computer stops if the BIOS detect a hardware error. This setting
determines which type of error will cause the system to halt during boot. The options are:
All Error: Whenever the BIOS detects a non-fatal error, the system will be stopped and you will be
prompted.
No Errors: The system boot will not stop for any error that may be detected.
All, But Keyboard: The system boot will not stop for a keyboard error, but it will stop for all others.
All, But Diskette: The system boot will not stop for a disk error, but it will stop for all others.
All, But Disk/Key: The system boot will not stop for a keyboard or disk error, but it will stop for all others.
EBC575 User's Manual
No floppy drive installed
5-1/4 inch PC type standard drive; 360 kilobyte capacity
5-1/4 inch AT-type high-density drive; 1.2 megabyte capacity
3-1/2 inch double-sided drive; 720 kilobyte capacity
3-1/2 inch double-sided drive; 1.44 megabyte capacity
3-1/2 inch double-sided drive; 2.88 megabyte capacity
Enhanced Graphics Adapter/Video Graphics Array. For EGA, VGA, SEGA or PGA
monitor adapters
Color Graphics Adapter, power up in 40 column mode
Color Graphics Adapter, power up in 80 column mode
Monochrome adapter, includes high resolution monochrome adapters
