Current SILENT TRAC Installation Manual

Wall mount drapery track
Hide thumbs Also See for SILENT TRAC:

Advertisement

Quick Links

Download this manual
Wall Mount
Installation Guide
Wall Mount Drapery Track Installation and Connecting the Motors
..........2
Table 1: Wall Mount Single Bracket Spacing Guidelines
..........4
Table 2: Wall Mount Dual Bracket Spacing Guidelines
..........5
Start Up
..........12
Statements
..........14
1

Advertisement

loading

Related Manuals for Current SILENT TRAC

Summary of Contents for Current SILENT TRAC

  • Page 1 Wall Mount Installation Guide Wall Mount Drapery Track Installation and Connecting the Motors ..2 Table 1: Wall Mount Single Bracket Spacing Guidelines ..4 Table 2: Wall Mount Dual Bracket Spacing Guidelines ..5 Start Up ..12 Statements ..14...
  • Page 2 Wall Mount Drapery Track Installation For additional help during installation of your drapery track, visit www.currentproductscorp.com/support/drapery-track or call 1-844-307-7435. For proper installation of your track drapery, the following tools are required: 1/4” nut driver 5/64” hex screwdriver (spliced tracks only) 6”...
  • Page 3 I. Wall Mount DRapery Track Installation Double check drapery height, drapery width, and track length before beginning your installation. The width of your panels should be large enough to cover the length of your track plus any return distance, plus any overlap in the case of a center draw application.
  • Page 4 Reference the bottom side of the wall bracket camlock protrusion and align with the horizontal mark on the wall. See Figure 4. Wall Bracket Camlock Prior to mounting hardware, double check levelness and parallelism Protrusion with ceiling and floor. Check for levelness and height correctness. In some cases it is more important aesthtically to maintain uniform clearance of the drapery with the floor.
  • Page 5 Table 2: Wall Mount DUAL Bracket Spacing Guidelines Bracket spacing based on drywall installation using wall anchors. Rear Curtain Weight/ft Front Curtain 0.25 - 0.50 0.51 - 1.00 1.01 - 1.50 1.51 - 2.00 2.01 - 2.50 2.51 - 3.00 3.01 - 3.50 Weight/ft Bracket Spacing 0.25 - 0.50...
  • Page 6 Pro Tip: The track can be used as a straight edge to help locate the correct position of interior wall brackets. Once the outer brackets have been installed, place the track on the top of the outer bracket with the carriers facing up. Check the levelness and the distance to the floor.
  • Page 7 2. INSTALL THE TRACK Before installing the track, measure the length of the track to determine the centerline. Begin with the camlocks in the open position. See Figure 15. Mark the centerline of the track. Figure 15 - Camlock in open position On unspliced tracks, starting in the middle, secure the track onto each of the brackets using each camlock.
  • Page 8 3. ADJUST NUMBER OF CARRIERS AND ORIENT THE CARRIER ARMS It may be necessary to add or remove carriers based on the curtain size, fullness, and pleat spacing. To add or remove carriers, remove the motor if it is installed. Then, loosen the hardstop screw and slide it out of the track.
  • Page 9 Slide the hardstop back into the track and secure with screw. See Figure 23. Figure 23 - Slide hardstop back into track and secure with screw 3. CONNECT THE MOTORS On a single drapery, insert the motor shaft onto the motor end of the drapery track and twist the motor into place.
  • Page 10 4. CONNECT THE SENSOR BOX (Optional) Place and install the sensor box behind the drapery in a place where the Pendant is still accessible and the sensors will still detect light coming in from the window. See Figure 28. Figure 28 - Sensor box placement Screw the wall plate into the desired location, using wall anchors if necessary, then slide the sensor box over the plate until it sits securely.
  • Page 11 Wrap the remaining fabric around each control end by hooking the drapery onto the recess clips on each end. See Figure 34 for pin connector options and see Figure 35 for proper placement on the track ends. Figure 34 - Pin connector placement options Figure 35 - Snap in pin connector In some cases, it is desirable to connect the return of the drapery to the wall with an eye hook.

  • Page 12: Connect Power

    II. Start up 1. CONNECT POWER On battery powered units, untwist the Pendant and insert (6) or (8) D Alkaline batteries, negative end first. See Figure 38. Figure 38 - Insert Batteries into the Pendant Twist the Pendant lock to secure back onto the unit. See Figure 39. Figure 39 - Screw the Pendant onto the Cord On rechargeable battery powered units, twist the Pendant lock to secure onto the unit.
  • Page 13 Power up by plugging the power input into the jack at the bottom of the Pendant, and plugging the wall port into the desired outlet. See Figure 43. Figure 43 - Plug input into bottom of Pendant and plug into wall outlet On units with power and control over CAT5, run the wire as desired to the power and communication port.

  • Page 14: Fcc Statement

    Warning: Changes or modifications not expressly approved by Current Products Co. could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
  • Page 15 844-307-7435 support@currentproductscorp.com www.currentproductscorp.com...
