MULTITEST 1 SPECIFICATIONS
Load capacity
Power consumption
Weight (stand only)
CROSSHEAD MOTION
Travel range
Maximum daylight
Maximum headroom
Speed range
Up and down settings
Stand speed indicated
Direction of travel indicated
Limit switch repeatability
Over-run at top speed
Operating modes
Reverse on alarm point
Reverse on sample break
ENVIRONMENTAL OPERATING CONDITIONS
Temperature range
Humidity
STANDARD LOAD MEASUREMENT OPTIONS
Force Gauge and dovetail bracket
Anvil plate
S-beam Loadcell, tension
block module & AFTI
SPECIAL OPTIONS
Increased crosshead travel
Increased crosshead depth
Machine guard
Horizontal operation
Simple logging/plotting PC software
Full computer control
Internal storage of test programs
1000N/100kgf/220lbf
60 watts (maximum)
20kg (44lb)
500mm (19.68in)
630mm (24.80in)
510mm (20.08in)
2.5 - 1000mm/min
by toggle switch
by potentiometer/graduated dial
LED
< 0.5mm (0.020in)
< 2mm (0.08in)
Manual & single cycle with fast return
Yes, with AFG or AFTI cable
Yes, with AFG or AFTI cable
5ºC to 40ºC
< 92.5%
Yes
Yes
Yes
No
Yes, reduced load capacity
Yes
Yes
DataPlot (see document M/501201)
MultiTest 1- i
MultiTest 1- x
page 5
