Assembly and Owner's Manual
OnBoard
Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Moving the Podium . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Attach the Boundary Rails. . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Podium to the Performance Position . . . . . . . . . . . . . . . . . . 8
Podium to the Stored Position . . . . . . . . . . . . . . . . . . . . . . . 9
Remove the Boundary Rails . . . . . . . . . . . . . . . . . . . . . . . . . 10
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Replacement Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Printed in USA 2021-06
Field Podium
®
Part #210A474-02
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Wenger OnBoard 210A018
Summary of Contents for Wenger OnBoard 210A018
-
Page 1: Table Of Contents
Visit the OnBoard Field Podium web page at wengercorp.com for more information. Note: Please read and understand these instructions before assembling or operating. Note: If you need additional information, contact Wenger Corporation using the information below. ©Wenger Corporation 2021 Printed in USA 2021-06 Part #210A474-02 Wenger Corporation, 555 Park Drive, P.O. -
Page 2: Important User Information
Wenger Corporation. Wenger Corporation does not assume any responsibility for any errors that may appear in these instructions. In no event will Wenger Corporation be liable for technical or editorial omissions made herein, nor for direct, indirect, special, incidental, or consequential damages resulting from the use or defect of these instructions. -
Page 3: Safety Precautions
Safety Precautions Throughout this document you may find cautions and warnings which are defined as follows: • WARNING: Failure to follow the instruction could result in serious injury or damage to property. • CAUTION: Failure to follow the instruction could result in minor injury or damage to property. Read all of these safety instructions before using the equipment. -
Page 4: Required Tools
Required Tools • 9/16" wrench • 9/16" socket and wrench Fasteners Any fasteners remaining when the assembly is complete can be discarded. 3/8"-16x1 3/8"-16 Carriage Bolt Lock Nut Parts List Item Qty Description Item Qty Description Podium Base Assembly Tow Bar 8"... -
Page 5: Assembly
Assembly 1. Attach the rigid casters (#3). a. Elevate the left side of the podium base assembly frame (#1). b. Align a rigid caster (#3) with the pilot holes as shown and attach it to the frame using four 3/8" carriage bolts (#7) and lock nuts (#8). c. -
Page 6: Operation
Operation Moving the Podium CAUTION • When moving the podium, speed should not to exceed 5 mph (8 kph). • Never move or position the podium sideways on an incline. • Avoid ramps steeper than a 1' (305 mm) rise or drop in a 12' (3658 mm) horizontal distance. •... -
Page 7: Attach The Boundary Rails
Operation (continued) Attach the Boundary Rails 1. With the podium in the stored position, insert the boundary rails (#5) in the cut-out slots on the deck. 2. Tighten the knobs on the underside corners of the deck to secure the rails. Tighten Knob... -
Page 8: Podium To The Performance Position
Operation (continued) Podium to the Performance Position CAUTION These steps require two people. Keep hands clear of pinch points. 1. Lift one end of the podium into the upright position. a. With a person on each side of the podium, lift the top handle. -
Page 9: Podium To The Stored Position
Operation (continued) Podium to the Stored Position CAUTION These steps require two people. Keep hands clear of pinch points. 1. With one person on each side of the podium, lift the latch. Latch 2. Grasp the top handle with one hand and push the center handle inward with the other hand. -
Page 10: Remove The Boundary Rails
Operation (continued) Remove the Boundary Rails 1. With the podium in the stored position, loosen the knobs on the underside corners of the deck to release the boundary rails. 2. Remove the rails. 3. Store the rails on top of the podium deck. Tightening Knob Maintenance... -
Page 11: Replacement Parts List
Replacement Parts List Item Description Item Description Drum Major Podium Deck Assembly Shoulder Bolt, 5/16-18 x 3/8" 8" Swivel Locking Casters Corner Bracket, LH 8" Rigid Casters Hex Nut, 3/8-16 Tow Bar Capscrew, 3/8"-16 x 1-1/2" Boundary Rail Caster Bracket Wheel Stop Bumper Carriage Bolt, 3/8-16 x 1"... - Page 12 Replacement Parts List (continued)
