Integrated Peripherals

Internal PCI/IDE
IDE Primary Master PIO
IDE Primary Slave PIO
IDE Burst Mode
IDE Data Port Post Write
IDE HDD Block Mode
Onboard FDC Controller
Onboard UART 1
Onboard UART 2
Onboard Parallel Port
Parallel Port Mode
PS/2 Mouse Function
WDT Configuration Port
IDE HDD Block Mode
This allows your hard disk controller to use the fast block mode to transfer data to
and from your hard disk drive (HDD).
Enabled
Disabled
Enabled is the default.
IDE PIO
IDE hard drive controllers can support up to two separate hard drives. These
drives have a master/slave relationship which are determined by the cabling
configuration used to attach them to the controller. Your system supports one IDE
BIOS Setup
ROM PCI / ISA BIOS (2A5IIN09)
INTEGRATED PERIPHERALS
AWARD SOFTWARE, INC.
: Primary Watch Dog Timer
: Auto WDT Time Out Active For
: Auto WDT Active Time
: Disabled USB Controller
: Enabled USB Keyboard Support
: Enabled
: Enabled
: Auto
: Auto
: 278/IRQ5
: Normal
ESC : Quit
F1 : Help
: Enabled
F5 : Old Values
: F2h
F6 : Load BIOS Defaults
F7 : Load Setup Defaults
IDE controller uses block mode.
IDE controller uses standard mode.
: Disabled
: Reset
: 64 sec.
: Disabled
: Disabled
↑ ↓ → ←: Select Item
PU/PD/+/- : Modify
(Shift) F2 : Color
