- Page 1 062-3428-8 SHALLOW WELL JET PUMP with 6 U.S. Gallon (22 L) Tank IMPORTANT: INSTRUCTION Please read this manual carefully before running MANUAL this pump and save it for reference.
- Page 2 062-3428-8 | contact us 1-800-689-9928...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Technical Specifications Important Instructions Grounding Instructions Key Parts Diagram Parts List Installation Instructions Operating Instructions Maintenance Troubleshooting Warranty NOTE: If any parts are missing or damaged, or if you have any questions, please call our toll-free helpline at 1-800-689-9928. SAVE THESE INSTRUCTIONS This manual contains important safety and operating instructions. -
Page 4: Technical Specifications
062-3428-8 | contact us 1-800-689-9928 TECHNICAL SPECIFICATIONS Model Number 062-3428-8 Electrical Rating 120 V / 60 Hz / 5 A Inlet / Outlet Diameter 1" (2.5 cm) NPT Maximum Flow 950 U.S. GPH (3596 L/h) Maximum Suction Lift 26' (7.9 m) -
Page 5: Important Instructions
IMPORTANT INSTRUCTIONS For your own safety − before starting to run the pump, please have the following items checked by an expert: 1. Risk of electric shock − This pump is supplied with a grounding conductor and grounding-type attachment plug. To reduce the risk of electric shock, connect only to a properly grounded, grounding-type receptacle. -
Page 6: Grounding Instructions
062-3428-8 | contact us 1-800-689-9928 GROUNDING INSTRUCTIONS To prevent electric shock and death from incorrect grounding wire connection, read and follow these instructions: Check with a qualified electrician if you are in doubt as to whether the outlet is properly grounded. -
Page 7: Key Parts Diagram
KEY PARTS DIAGRAM Description Priming inlet Discharge Air valve (hidden) Intake Pressure gauge... -
Page 8: Parts List
062-3428-8 | contact us 1-800-689-9928 PARTS LIST 22 23... - Page 9 PARTS LIST Description Qty. Description Qty. Flexible pipe Screw Pressure gauge Screw Pipe connection Stator Screw Terminal O-ring Insulated flexible pipe Dust cover Insert spring Screw Screw Pump body Double voltage transfer switch O-ring Capacitor Injector Terminal cover O-ring Screw Diffuser Screw Hexangular nut...
-
Page 10: Installation Instructions
062-3428-8 | contact us 1-800-689-9928 INSTALLATION INSTRUCTIONS The well motor pump must be installed in a stationary position with a fixed pipeline and a steady water supply. Please Note! 1. Remove the screw from the front of the unit to connect the power to the heater. - Page 11 1. The illustration below shows an example of a proper Outlet Water Level shallow well pump installation. The total suction lift (vertical well lift and length of off-set line) must not exceed the maximum suction lift. NOTE: Check Valve • This pump is intended for shallow well application only Length of Off-set Line and is not intended to be used...
-
Page 12: Operating Instructions
062-3428-8 | contact us 1-800-689-9928 OPERATING INSTRUCTIONS 1. The compression has a rubber bladder inside. This bladder must be pumped up to 23 PSI of air at all times. Use a bicycle pump (not included) to inflate the bladder. -
Page 13: Maintenance
MAINTENANCE 1. Clean the inlet screen on the intake port regularly to remove accumulated debris. 2. Wipe the pump clean with a soft, damp cloth dampened with soapy water. Do not use solvents. Do not get the electrical components wet. 3. -
Page 14: Troubleshooting
062-3428-8 | contact us 1-800-689-9928 TROUBLESHOOTING Problem Possible Cause Corrective Action The pump 1. No power. 1. Check connections, and breaker/fuse. won't start. 2. Pressure switch disconnected. 2. Check gauge. 3. Thermal protection activated. 3. Allow pump to cool. -
Page 15: Warranty
PLEASE DO NOT ATTEMPT TO OPEN OR REPAIR THE PUMP YOURSELF. DOING SO COULD VOID THE WARRANTY AND CAUSE DAMAGE OR PERSONAL INJURY. This Mastercraft product carries a three (3) year LIMITED warranty against defects in workmanship and materials. This product is not guaranteed against wear or breakage due to misuse and/or abuse.
