- Page 1 2-IN-1 SUBMERSIBLE UTILITY PUMP/ NON-SUBMERSIBLE TRANSFER PUMP Model No. 062-3408-6 IMPORTANT: INSTRUCTION Please read this manual carefully before running this MANUAL utility pump and save it for reference.
- Page 2 headline bars headline bars continuation tabs notes continuation tabs warnings notes warnings...
- Page 3 TABLE OF CONTENTS Quick Start Guide Technical Specifications Safety Guidelines Key Parts Diagram Assembly Preparation Assembly Instructions—Submersible Utility Pump Operating Instructions—Submersible Utility Pump Assembly Instructions—Non-submersible Transfer Pump Operating Instructions—Non-submersible Transfer Pump Maintenance Troubleshooting Warranty NOTE: If any parts are missing or damaged, or if you have any questions, please call our toll-free helpline at 1-800-689-9928.
- Page 4 062-3408-6 | contact us 1-800-689-9928 Submersible Utility Pump Function CONNECTING GARDEN HOSE Attach a garden hose with a 3/4" (19 mm) garden hose thread (not included) to the pump outlet. 3/4" (19 mm) NH...
- Page 5 Non-submersible Transfer Pump Function ATTACHING THE SUCTION HOSE TO STRAINER Attach the clear suction hose to the suction strainer. Then, place the strainer in at least 1" (2.5 cm) of water at the lowest point to be pumped. 1" (2.5 cm) 3/4"...
- Page 6 062-3408-6 | contact us 1-800-689-9928 TECHNICAL SPECIFICATIONS Liquid temperature range 32 to 95°F (0 to 35°C) Impeller Plastic Discharge size 3/4" (19 mm) garden hose thread connection Seal Lip seal Cord length 10’ (3 m)
- Page 7 PERFORMANCE CHART Lift in feet/ 0’ 5’ 10’ 15’ 20’ 25’ metres (0 m) (1.5 m) (3 m) (4.6 m) (6 m) (7.6 m) Submersible Utility U.S. gallons/ 1600 1500 1300 Pump Function litres per hour (6,056) (5,678) (4,921) (3,596) (2,649) (794) Non-submersible...
- Page 8 • Mastercraft Canada is not responsible for losses, injury, or death resulting from a failure to observe these safety precautions, or the misuse or abuse of pumps or equipment.
- Page 9 STORAGE • Short Term—Pumps are manufactured for efficient performance following short, inoperative periods in storage. For best results, pumps can be retained in storage, as factory assembled, in a dry atmosphere with constant temperatures for up to six (6) months. •...
- Page 10 062-3408-6 | contact us 1-800-689-9928 SAFETY GUIDELINES WIRE SIZE • Consult a qualified electrician for proper wire size. PRE-OPERATION: CHECK VOLTAGE AND PHASE • Before operating pump, check to make sure that the voltage and phase information...
- Page 11 PARTS LIST Description Qty. Description Qty. Priming plug Power cord Suction hose Carry handle Motor housing Suction strainer Pump outlet...
- Page 12 062-3408-6 | contact us 1-800-689-9928 APPLICATION • This pump can be used as a submersible utility pump. It is suitable for draining or removing water from the following: pits, sinks, window wells, basements, swimming pool covers, boats, low spot in yards, or other flooded areas.
- Page 13 SUBMERSIBLE UTILITY PUMP INSTALLATION • Attach a garden hose with a 3/4" (19 mm) garden hose thread (not included) to the pump outlet. 3/4" (19 mm) NH thread • Place the pump on a solid base in flooded area or any place that you would like to remove water.
- Page 14 062-3408-6 | contact us 1-800-689-9928 OPERATION • Allow the pump to run and monitor its progress. • Unplug the pump when it has removed water down to approximately 1/2” (12.7 mm). • Remove the pump and hose from the location continuation tabs when finished pumping.
- Page 15 NON-SUBMERSIBLE TRANSFER PUMP INSTALLATION The following picture shows a typical installation. The suction lift of this unit can get up to 8' (2.4 m). Be sure to use the included, specially designed built-in check valve suction strainer. Priming plug Suction hose Suction strainer •...
- Page 16 062-3408-6 | contact us 1-800-689-9928 NON-SUBMERSIBLE TRANSFER PUMP INSTALLATION • Open the bottom cover. 3/4" (19 mm) NH thread • Thread the other end of the suction hose to the inlet of the pump.
- Page 17 CARE AND CLEANING DO NOT When the power is disconnected, Do not disassemble the motor housing. inspect the pump suction screen and This motor has NO repairable internal remove all debris, then plug the pump parts, and disassembly may cause leakage back into the grounded (GFCI) outlet.
- Page 18 062-3408-6 | contact us 1-800-689-9928 SUBMERSIBLE UTILITY PUMP FUNCTION Problem Possible Causes Corrective Action Pump does not start 1. The fuse is blown. 1. Replace the fuse. or run. 2. The breaker is tripped. 2. Reset the breaker.
- Page 19 This Mastercraft product is guaranteed for a period of one (1) year from the date of original retail purchase, against defects in materials and workmanship. Subject to the conditions and limitations described below, this product, if returned to us with proof of purchase within the stated warranty period and if covered under this warranty, will be repaired or replaced (with the same model, or one of equal value or specification), at our option.
