PHASE 7.2
OPL
USER'S MANUAL
For replacement parts, contact the distributor from which the dryer
was purchased or contact:
Maytag Co.
403 West Fourth St North
Newton, Iowa 50208
(515) 787-7000
122002JEV/mcronan
Part No. 113162

Advertisement

Table of Contents
loading

Related Manuals for Maytag PHASE 7.2

Summary of Contents for Maytag PHASE 7.2

  • Page 1 PHASE 7.2 USER’S MANUAL For replacement parts, contact the distributor from which the dryer was purchased or contact: Maytag Co. 403 West Fourth St North Newton, Iowa 50208 (515) 787-7000 122002JEV/mcronan Part No. 113162...
  • Page 2 This manual contains important information on how to employ ALL the features of your new Maytag dryer in the safest and most economical way. Our products embody advanced concepts in engineering, design, and safety. If this product is properly maintained, it will provide many years of safe, efficient, and trouble free operation.
  • Page 3 IMPORTANT YOU MUST DISCONNECT AND LOCKOUT THE ELECTRIC SUPPLY AND THE GAS SUPPLY OR THE STEAM SUPPLY BEFORE ANY COVERS OR GUARDS ARE REMOVED FROM THE MACHINE TO ALLOW ACCESS FOR CLEANING, ADJUSTING, INSTALLATION, OR TESTING OF ANY EQUIPMENT PER OSHA (Occupational Safety and Health Administration) STANDARDS.
  • Page 4 WARNING DRYER MUST NEVER BE OPERATED WITHOUT THE LINT FILTER OR SCREEN IN PLACE, EVEN IF AN EXTERNAL LINT COLLECTION SYSTEM IS USED. IMPORTANT PLEASE OBSERVE ALL SAFETY PRECAUTIONS displayed on the equipment and specified in the installation manual included with the dryer. Dryers must not be installed or stored in an area where it will be exposed to water or weather.

  • Page 5: Table Of Contents

    Table of Contents SECTION I INTRODUCTION ....................... 3 SECTION II FEATURES........................4 A. Dependable Microprocessor Solid State Integrated Circuitry ............4 B. Sensor Activated Fire Extinguishing (S.A.F.E.) System ..............4 C. Program Changes Are Easily Made At The Keyboard (Touch Pad) ..........4 D.
  • Page 6 K. Reversing Option ........................10 L. Diagnostics ..........................10 M. Program Locations ........................11 SECTION IV OPERATING INSTRUCTIONS ................13 A. Operating Sequence ......................... 13 B. Operating Notes ........................17 C. Rev 2.2 Sensor Activated Fire Extinguishing (S.A.F.E.) System Theory Of Operation ....18 SECTION V L.E.D DISPLAY MESSAGES .................

  • Page 7: Introduction

    SECTION I INTRODUCTION Phase 7 “On-Premise Laundry” Microprocessor Drying System The Phase 7 On-Premise Laundry (OPL) Drying System has been designed with super performance in mind to provide for better temperature regulation, efficiency, performance, consistency, and faster drying times. Among its many amenities, the Phase 7 OPL Drying System has a true Automatic Drying Cycle. The Phase 7 OPL Automatic Drying Cycle (Patent No.

  • Page 8: Features

    SECTION II FEATURES A. Dependable Microprocessor Solid State Integrated Circuitry - To eliminate as many moving parts as possible. B. Sensor Activated Fire Extinguishing (S.A.F.E.) System - A standard feature, which continually monitors the basket (tumbler) for fires, in the event of a fire a water supply to the basket (tumbler) will suppress the fire.

  • Page 9: High-Temperature Protection

    N. Temperature Conversion Status - Temperature related programs can be set in either Fahrenheit (ºF) or Celsius (ºC). ALL temperatures will automatically convert to the corresponding values (+/- 1º) when changes are made. O. High-Temperature Protection - If the Phase 7 OPL microprocessor controller (computer) senses that the temperature in the basket (tumbler) has exceeded 180º...

  • Page 10: Program Selections

    SECTION III PROGRAM SELECTIONS A. PREPROGRAMMED CYCLES “A-F” CYCLES The Phase 7 OPL microprocessor controller (computer) can store in its memory six (6) preprogrammed cycles (keys “A-F” on the keyboard [touch pad]). This allows the user to have the six (6) most commonly used cycles, requiring only the push of a single keyboard (touch pad) entry to start the dryer.

  • Page 11: Manually Loaded Cycles

    c. Dryness Level - Programmable for finishing, dry, and extra dry. d. Cool Down Time - Programmable from 0 to 99 minutes in 1 minute increments. e. Cool Down Temperature - Programmable from 70º F to 100º F (21º C to 38º C) in one-degree increments. f.

  • Page 12: Automatic Drying Cycle (Patent No. 4,827,627) Operations

    C. AUTOMATIC DRYING CYCLE (PATENT NO. 4,827,627) OPERATIONS In this mode, the Phase 7 OPL microprocessor controller (computer) determines how much drying time is needed and compensates for various types of fabrics and load sizes, ALL automatically. The Phase 7 OPL microprocessor controller (computer) accomplishes this by calculating the dryness level (percentage of extraction) using the temperature selected, as well as, the dryness level preset by the factory.

  • Page 13: Cycle In Progress Temperature Display

    F. CYCLE IN PROGRESS TEMPERATURE DISPLAY While the dryer cycle is in progress, the temperature in the basket (tumbler) can be displayed by pressing and holding the “UP ARROW” key. The temperature will be displayed in either Fahrenheit (ºF) or Celsius (ºC), depending on what the system temperature has been set for in “DRYER SETUP.”...

  • Page 14: Audio Alert On Times 0 To 10

    I. AUDIO ALERT ON TIMES 0 TO 10 The tone will sound at the end of the Cool Down Cycle to indicate that the cycle is complete. Programming allows for the elimination of the tone during the Wrinkle Guard Cycle. This is done in “WRINKLE GUARD SETUP.”...

  • Page 15: Program Locations

    M. PROGRAM LOCATIONS This is where system parameters are programmed. These system parameters (programs) are stored in memory. Access to this location is acquired by pressing the “STOP/CLEAR” and the “UP ARROW” together. To o exit the Programming Location, simply press the “STOP/CLEAR” key.
  • Page 16 3. ENTER AUDIO ALERT ON TIMES 0 TO 10 - This selection allows the operator to adjust the amount of signal tones. This parameter (program) affects the tone at the end of the Cool Down Cycle, as well as, at the end of the Wrinkle Guard On Time. 4.

  • Page 17: Operating Instructions

    SECTION IV OPERATING INSTRUCTIONS The Phase 7 OPL microprocessor controller (computer) allows the operator to choose from six (6) preprogrammed cycles (keys “A-F”). These have been preprogrammed by the factory with the parameters (programs) shown in Section VII. There are an additional (“0-40”) preprogrammable cycles that are preprogrammed by the factory with the parameters (programs) shown in Section VII.
  • Page 18 5) Once the preprogrammed percentage of extraction (dryness level) is reached, the drying cycle will end and the Cool Down Cycle will begin. 6) Once the Cool Down Cycle begins at the end of the heat cycle, the light emitting diode (L.E.D.) display will read COOL DOWN TEMP ___/___ MINUTES REMAINING.
  • Page 19 7) Once the Cool Down Cycle is completed the Phase 7 OPL microprocessor controller (computer) will proceed into the Wrinkle Guard Cycle. The Audio Alert tone will sound (for amount set in Audio Alert On Time). The light emitting diode (L.E.D.) display will read “WRINKLE GUARD.” The times are fixed at 2 minutes OFF, 2 minutes ON for a maximum time of 99 minutes.
  • Page 20 NOTE: Press and hold the “DOWN ARROW” to view the basket (tumbler) RPM. 7) Once the preprogrammed percentage of extraction (dryness level) is reached, the drying cycle will end, and the Cool Down Cycle will begin. 8) Once the Cool Down Cycle begins at the end of the heat cycle, the light emitting diode (L.E.D.) display will read COOL DOWN TEMP ___/___MINUTES REMAINING.

  • Page 21: Operating Notes

    NOTE: The dryer can be stopped at any time by pressing the “STOP/CLEAR” key, at this time the dryer will go into a cycle pause. If the “STOP/CLEAR” key is pressed again at this point, the cycle that was in progress will be cancelled and returned to the “READY” state. 8) Once the programmed drying time has expired, the Phase 7 OPL microprocessor controller (computer) will proceed into the Cool Down Cycle (mode).

  • Page 22: Rev 2.2 Sensor Activated Fire Extinguishing (S.a.f.e.) System Theory Of Operation

    6. In the programming mode, the number of keys can be used to jump to menu levels without scrolling through them ALL. I.E., from 0 select Model in “DRYER SETUP”; you can jump to menu level five (5). Enter lint count under “DRYER SETUP”...

  • Page 23: Display Messages

    SECTION V L.E.D. DISPLAY MESSAGES The light emitting diode (L.E.D.) display informs the operator of cycle status, program verification, and displays important diagnostic messages and fault information. A. L.E.D. DISPLAY OPERATING STATUS 1. Cycles in Progress a. While the dryer is operating, the L.E.D. display will read which cycle is in progress. I.E., in a Manual Drying Cycle (mode), the L.E.D.

  • Page 24: Programming Instructions

    SECTION VI PROGRAMMING INSTRUCTIONS A. INTRODUCTION TO PROGRAMMING The various program selections are stored in the Phase 7 OPL microprocessor controller (computer) and are broken down into five (5) categories: 0. Language (ENGLISH, FRANCAIS, ESPANOL, ITALIANO, and DEUTSCH). 1. System Parameters (Dryer Setup, Display Setup, Cool Down Setup, and Wrinkle Guard Setup). 2.
  • Page 25 If the parameter (program) change is a feature change, such as changing the temperature PHASE 7 OPL conversion from degree Fahrenheit (ºF) to PROGRAMMING LOCATIONS degree Celsius (ºC) or from “AUTO” TO ENTER PROGRAMMING MODE PRESS KEYS TOGETHER. (Automatic Drying Cycle - [Patent No. TO EXIT PROGRAMMING MODE PRESS MULTIPLE TIMES 4,827,627]) to “MANUAL”...

  • Page 26: Programming Flowcharts

    B. PROGRAMMING FLOWCHARTS The following section of this manual explains the programming of the preprogrammed cycles and Program Locations (system parameters) through the use of flowcharts. A flowchart is nothing more than a diagram of the programming process. Four (4) different symbols will be used in these flowcharts: display symbol Ready key symbol...
  • Page 27 PHASE 7 MENU PROGRAMMING PROCEDURE EVERY INDENTED STEP REPRESENTS THE “START/ENTER” KEY BEING PRESSED TO SELECT A MENU ITEM. EVERY MESSAGE WITH A NUMBER BEFORE IT, INDICATES THAT IT IS A MENU SELECTION CHOICE. EVERY MESSAGE WITHOUT A NUMBER BEFORE IT, INDICATES THAT IT IS THE LAST MENU LEVEL.
  • Page 28 0: SELECT LANGUAGE ENGLISH FRANCAIS ESPANOL ITALIANO DEUTSCH 1: SELECT SYSTEM PARAMETERS 0: DRYER SETUP 0: SELECT MODEL GAS (Reversing) ELECTRIC (Reversing) STEAM (Reversing) GAS (Non-Reversing) ELECTRIC (Non-Reversing) STEAM (Non-Reversing) 1: SYSTEM TEMP DEG F DEG C 2: ENTER LINT COUNT 1 TO 5 (5 = DEFAULT VALUE) 3: ENTER AUDIO ALERT ON TIMES 0 TO 10 (5 = DEFAULT VALUE)
  • Page 29 2: PROGRAM “A-F” CYCLE SELECT “A-F” KEY (“*” DISPLAY THE LETTER CHOSEN. DEFAULTS TO “A”) SELECT CYCLE TYPE (“*” DISPLAY THE CYCLE TYPE “AUTO” or “MANUAL”) AUTO 0: REVERSE MODE 1: ENTER DRY TEMP 160º TO 200º F (71º C TO 93º C) *** F (“***”...
  • Page 30 3: PROGRAM “0-40” CYCLE 1: SEE 2: PROGRAMMING A-F CYCLES 4: DEFAULT SETTINGS ENTER PASSWORD (PRESS “1” “2” “3”) CONFIRM DEFAULTS (DEFAULT VALUE)
  • Page 31 Selecting Languages NOTE: The computer must display Ready ready to enter program mode Press and hold the stop/clear key While holding the stop/ clear key, press the up arrow key. 0:SELECT LANGUAGE Press ENTER to access ENGLISH Press the up or down arrow key to select a different language.
  • Page 32 Selecting a Dryer Model The computer must be displaying READY While holding the stop/ Ready to enter program mode clear key, press the up arrow key. 0:SELECT Press and hold the LANGUAGE stop/clear key Or number Use arrow Press ENTER to jump directly to the location 1: SELECT SYSTEM PARAMETERS...
  • Page 33 From Previous Press ENTER to access GAS REVERSING Press the up or down arrow key to select a different model. GAS REVERSING, ELECTRIC REVERSING, STEAM REVERSING, GAS NON- REVERSING, ELECTRIC NON-REVERSING and STEAM NON-REVERSING are the selections. ELECTRIC REVERSING Press ENTER to store new changes 1: SYSTEM TEMP...
  • Page 34 Selecting the System Temperature While holding the stop/ Ready clear key, press the up arrow key. 0:SELECT Press and hold the LANGUAGE stop/clear key Or number Use arrow Press ENTER to jump directly to the location 1: SELECT SYSTEM PARAMETERS Press ENTER to access 0: DRYER SETUP Press ENTER to access...
  • Page 35 From Previous Use arrow Or number Press ENTER to jump directly to the location 1: SYSTEM TEMP Press ENTER to access DEG F Press the up or down arrow key to select DEG F or DEG C DEG C Press ENTER to store new changes 2: ENTER LINT COUNT 1 TO 5...
  • Page 36 Setting the Lint Count While holding the stop/ Ready clear key, press the up arrow key. 0:SELECT Press and hold the LANGUAGE stop/clear key Or number Use arrow Press ENTER to jump directly to the location 1: SELECT SYSTEM PARAMETERS Press ENTER to access 0: DRYER SETUP Press ENTER to access...
  • Page 37 From Previous Use arrow Or number 1: SYSTEM TEMP Press ENTER to jump directly to the location 2: ENTER LINT COUNT 1 TO 5 Press ENTER to access Press the up arrow key to increment the number, down arrow key to decrement the number or enter the number directly.
  • Page 38 Adjusting the Audio Alert On times While holding the stop/ Ready clear key, press the up arrow key. 0:SELECT Press and hold the LANGUAGE stop/clear key Or number Use arrow Press ENTER to jump directly to the location 1: SELECT SYSTEM PARAMETERS Press ENTER to access 0: DRYER SETUP...
  • Page 39 From Previous Use arrow Or number 1: SYSTEM TEMP Press ENTER to jump directly to the location 2: ENTER LINT COUNT 1 TO 5 3: ENTER AUDIO ALERT ON TIMES 0 TO 10 Press ENTER to access Next page...
  • Page 40 Next page Press the up arrow key to increment the number, down arrow key to decrement the number or enter the number directly. Press ENTER to store new changes 4: ROTATION SENSOR...
  • Page 41 Rotation Sensor While holding the stop/ Ready clear key, press the up arrow key. 0:SELECT Press and hold the LANGUAGE stop/clear key Or number Use arrow Press ENTER to jump directly to the location 1: SELECT SYSTEM PARAMETERS Press ENTER to access 0: DRYER SETUP Press ENTER to access 0: SELECT...
  • Page 42 From Previous Use arrow Or number 1: SYSTEM TEMP 2: ENTER LINT COUNT 1 TO 5 Press ENTER to jump directly to the location 3: ENTER AUDIO ALERT ON TIMES 0 TO 10 4: ROTATION SENSOR Next page...
  • Page 43 From Previous Press ENTER to access Press the up or down arrow key to select ON or OFF Press ENTER to store new changes 4: ROTATION SENSOR...
  • Page 44 Adjusting Reversing Spin Time and Stop Time While holding the stop/ Ready clear key, press the up arrow key. 0:SELECT Press and hold the LANGUAGE stop/clear key Use arrow Or number Press ENTER to jump directly to the location 1: SELECT SYSTEM PARAMETERS Press ENTER to access 0: DRYER SETUP...
  • Page 45 Next Next Page (A) Page (B) 1: REVERSING SETUP Press ENTER to access 0: ENTER SPIN TIME 30 TO 120 SECONDS Press ENTER to access Press the up arrow key to increment the time, down arrow key to decrement the time or enter the time directly.
  • Page 46 From Previous Press ENTER to access Press the up arrow key to increment the time, down arrow key to decrement the time or enter the time directly. The stop time is adjustable from 5 to 10 seconds. Press ENTER to store new changes 1: ENTER STOP TIME 5 TO 10 SECONDS...
  • Page 47 Wrinkle Guard Audio Alert While holding the stop/ Ready clear key, press the up arrow key. 0:SELECT Press and hold the LANGUAGE stop/clear key Use arrow Or number Press ENTER to jump directly to the location 1: SELECT SYSTEM PARAMETERS Press ENTER to access 0: DRYER SETUP Use arrow...
  • Page 48 Next Next Page (A) Page (B) 2: WRINKLE GUARD SETUP Press ENTER to access 0: WRINKLE GUARD AUDIO ALERT Press ENTER to access Press the up or down arrow key to select ON or OFF Press ENTER to store new changes 0: WRINKLE GUARD AUDIO ALERT...
  • Page 49 Steam Injection Setup While holding the stop/ Ready clear key, press the up arrow key. 0:SELECT Press and hold the LANGUAGE stop/clear key Use arrow Or number Press ENTER to jump directly to the location 1: SELECT SYSTEM PARAMETERS Press ENTER to access 0: DRYER SETUP Use arrow Or number...
  • Page 50 Next Next Page (A) Page (B) 2: WRINKLE GUARD SETUP 3: STEAM INJECTION SETUP Press ENTER to access Press the up or down arrow key to turn the option ON or OFF. Press ENTER to store new changes. Note: If steam injection is OFF, when ENTER is pressed the program will jump back to 2: PROGRAM A - F CYCLE Next...
  • Page 51 From Previous ENTER 1ST ON TIME NOTE: Time Format is mm:ss 0:01 TO 45:00 The first time adjustment is Minutes 0:00 Press the up arrow key to increment the time in minutes, down arrow key to decrement the time in minutes or enter the time in minutes directly.
  • Page 52 From Previous Press ENTER to store new changes ENTER 1ST OFF TIME 5:11 TO 45:00 The first time adjustment is Minutes 0:00 Press the up arrow key to increment the time in minutes, down arrow key to decrement the time in minutes or enter the time in minutes directly.
  • Page 53 From Previous Press the up arrow key to increment the time in seconds, down arrow key to decrement the time in seconds or enter the time in seconds directly. Press ENTER to store new changes ENTER 2ND ON TIME 8:21 TO 45:00 The first time adjustment is Minutes 0:00 Press the up arrow key to increment...
  • Page 54 From Previous Press ENTER to store new changes The second time adjustment is 9: 00 Seconds :ss Press the up arrow key to increment the time in seconds, down arrow key to decrement the time in seconds or enter the time in seconds directly. Press ENTER to store new changes ENTER 3RD ON TIME...
  • Page 55 From Previous When 0 time is entered, the program will jump back to either 2: 0:00 PROGRAM A-F CYCLES or 3: PROGRAM 0-40 CYCLES. Press ENTER to store new changes 2: PROGRAM A-F CYCLES 3: PROGRAM 0-40 CYCLES...
  • Page 56 Programming A - F Cycles or 0 - 40 Cycles The computer must be displaying READY While holding the stop/ Ready to enter program mode clear key, press the up arrow key. 0:SELECT Press and hold the LANGUAGE stop/clear key (A - F Cycles) (0 - 40 cycles) (A - F Cycles)
  • Page 57 Previous Page SELECT A - F KEY ENTER 0 - 40 A or 0 Press the key (s) corresponding to the cycle you wish to program A - F or 0 - 40. Press ENTER to access SELECT CYCLE TYPE AUTO Follow this flow chart Follow this flow chart path...
  • Page 58 From From Previous Previous Press ENTER to access Press ENTER to store new changes Non reversing models will display "NOT AVAILABLE" 0: REVERSE and jump to 1: MODE ENTER DRY TEMP 160 TO 200ºF Press ENTER to access Press the Up or Down Arrow Key to turn reversing ON Non reversing...
  • Page 59 From From Press the up arrow Previous Previous key to increment the temp, down arrow key to decrement the temp or enter the temp directly. Press the up arrow key to increment the time, down arrow key to decrement the time or enter the time directly.
  • Page 60 From From Previous Previous Press the up or Press ENTER to store down arrow key to new changes adjust the dryness level. FINISHING, DRY OR EXTRA 1: ENTER DRY TIME 0 TO 99 MINUTES EXTRA DRY Press ENTER to access Press ENTER to store new changes 3: ENTER CYCLE...
  • Page 61 From From Previous Previous Press ENTER to access Press ENTER to store new changes 4: CONTROLLED COOL DOWN Press ENTER to access Press the up arrow key to increment the temp, down arrow key to decrement the temp or enter the temp directly.
  • Page 62 From From Previous Previous Press ENTER to store new changes. If CONTROLLED COOL DOWN is ON the program will display NOT Press the up or down AVAILABLE and jump to 6: arrow key to turn the ENTER COOL DOWN option ON or OFF. TEMP 70 TO 100 ºF when ENTER.
  • Page 63 From From Press the up arrow key Previous Previous to increment the temp, down arrow key to decrement the temp or enter temp directly. Press ENTER to store new changes 5: ENTER COOL DOWN TEMP 70 TO 100 ºF Press ENTER to access Press the up arrow key to increment the temp, down arrow...
  • Page 64 From Previous Press ENTER to access Press the up or down arrow key to turn the option ON or OFF. Press ENTER to store new changes. If STEAM INJECTION is OFF the program will jump back to 2: PROGRAM A - F CYCLE ENTER 1ST ON TIME NOTE: Time Format is mm:ss...
  • Page 65 From Previous Press ENTER to store new changes The second time adjustment is 5: 00 Seconds :ss Press the up arrow key to increment the time in seconds, down arrow key to decrement the time in seconds or enter the time in seconds directly. Press ENTER to store new changes ENTER 1ST OFF TIME...
  • Page 66 From Previous Press the up arrow key to increment the time in minutes, down arrow key to decrement the time in minutes or enter the time in minutes directly. Press ENTER to store new changes The second time adjustment is 8: 00 Seconds :ss Press the up arrow key to increment...
  • Page 67 From Previous ENTER 2ND ON TIME 8:21 TO 45:00 The first time adjustment is Minutes 0:00 Press the up arrow key to increment the time in minutes, down arrow key to decrement the time in minutes or enter the time in minutes directly. Press ENTER to store new changes The second time adjustment is...
  • Page 68 From Previous Press ENTER to store new changes ENTER 3RD ON TIME 8:21 TO 45:00 0:00 When 0 time is entered, the program will jump back to either 2: PROGRAM A-F CYCLES or 3: Press ENTER to store PROGRAM 0-40 CYCLES. new changes 0:00 Press ENTER to store...
  • Page 69 Restoring Factory Default Settings The computer must be displaying READY While holding the stop/ Ready to enter program mode clear key, press the up arrow key. 0:SELECT Press and hold the LANGUAGE stop/clear key Or number Use arrow 1: SELECT SYSTEM PARAMETERS 2: PROGRAM...
  • Page 70 From Previous ENTER PASSWORD CONFIRM DEFAULTS Press the Up or Down Arrow Key to toggle from NO to YES Next page...
  • Page 71 From Previous WARNING: Pressing enter will restore factory default settings including all preprogrammed cycles and any adjustments made to programming. DEFAULTS SET 4: DEFAULT SETTINGS...
  • Page 72 Fire Suppression Valve Test While holding the stop/ Ready clear key, press the up arrow key. 0:SELECT Press and hold the LANGUAGE stop/clear key Or press 5 1: SELECT SYSTEM PARAMETERS 2: PROGRAM A - F CYCLES 3: PROGRAM 0 - 40 CYCLES 4: DEFAULT SETTINGS Next...
  • Page 73 From From Previous Previous 5: FIRE SUPPRESSION VALVE TEST Press ENTER to access PRESS AND HOLD START TO OPEN FIRE SUPPRESSION SYSTEM VALVE The Fire Suppression system Valve will open as long as the START key is pressed. PRESS AND HOLD START TO OPEN FIRE SUPPRESSION SYSTEM VALVE...
  • Page 74 NOTE: “NO” WILL RETURN YOU BACK TO “4: DEFAULT SETTINGS” “YES” WILL SET ALL THE PARAMETERS TO THE DEFAULT SETTINGS. DISPLAY WILL READ “DEFAULTS SET” and RETURN TO “4: DEFAULT SETTINGS”...

  • Page 75: Factory Preset Parameters (Programs)

    SECTION VII FACTORY PRESET PARAMETERS (PROGRAMS) NOTE: To enter program mode press and hold the stop and press the up arrow. A. CYCLE “A-F” PARAMETERS (PROGRAMS) PRESET BY THE FACTORY CYCLE A: SELECT CYCLE TYPE = AUTO, 0:REVERSE MODE = ON, 1:ENTER DRY TEMP = 180°F, 2:ENTER DRYNESS LEVEL = EXTRA DRY, 3:ENTER CYCLE ADJUSTMENT VALUE = 70, 4:CONTROLLED COOL DOWN = OFF, 5:ENTER COOL DOWN TIME = 6 MINUTES, 5:ENTER COOL DOWN TEMP = 80°F CYCLE B:...

  • Page 76: Phase 7 Opl Programming Limits

    SECTION VIII PHASE 7 OPL PROGRAMMING LIMITS A. PREPROGRAMMED CYCLES 1. Automatic Drying Cycle (Patent No. 4,827,627) a. Drying Temperature from 160º F to 200º F (71º C to 93º C) in one-degree increments. b. Cycle Adjustment Value from 0-99 in increments of one (1). c.

  • Page 77: System Parameters (Program Locations)

    B. SYSTEM PARAMETERS (PROGRAM LOCATIONS) 1. Cycle Adjustment Value from 0 to 99 in increments of one (1). 2. Manually Loaded Auto Cycle (“COOL DOWN TIME”) from 0 to 99 minutes in 1 minute increments. 3. Audio Alert 0-10. 4. Lint Count 1-5. C.

  • Page 78: Phase 7 Auto Cycle (Patent No. 4,827,627) Cycle Adjustment Values

    EURO-35 IMPORTANT: If your particular model/dryer dryness levels are not shown in the above charts, contact the Maytag dealer Service Department for the appropriate factors for your particular dryer. When doing so, please have the dryer model and serial numbers available.

  • Page 79: Phase 7 Opl System Diagnostics

    SECTION X PHASE 7 OPL SYSTEM DIAGNOSTICS IMPORTANT: YOU MUST DISCONNECT AND LOCKOUT THE ELECTRIC SUPPLY AND THE GAS SUPPLY OR THE STEAM BEFORE ANY COVERS OR GUARDS ARE REMOVED FROM THE MACHINE TO ALLOW ACCESS FOR CLEANING, ADJUSTING, INSTALLATION, OR TESTING OF ANY EQUIPMENT PER OSHA (Occupational Safety and Health Administration) STANDARDS.

  • Page 80: Input/Output (I/O) Board Light Emitting Diode (L.e.d.) Indicators

    EE PROM FAULT ### - Error in memory location. The ### indicates the location of the fault. B. INPUT/OUTPUT (I/O) BOARD LIGHT EMITTING DIODE (L.E.D.) INDICATORS 1. INPUTS 1. ESTOP – (RED L.E.D.) This L.E.D. will indicate the status of the ESTOP. If the ESTOP has been pressed, then the L.E.D.
  • Page 81 2. OUTPUTS 9. AUX – (GREEN L.E.D.) This is for a spare output to be programmed. 10. STEAM – (GREEN L.E.D.) This light emitting diode (L.E.D.) will indicate the status of the steam injection output. If the request to turn on the steam injection is made, then the L.E.D.

  • Page 82: Keyboard (Touch Pad) Layout

    C. KEYBOARD (TOUCH PAD) LAYOUT 1. Dot Matrix Display 2. A-F Preprogrammed Cycles 3. Stop/Pause Button 4. Start Button 5. Increment Button 6. Decrement Button 7. One time auto (Dryness level) and manual (timed) Cycle NOTE: Fuse 1 is for computer power rated at 1/2-Amp. If fuse blows it is a computer board fault. Fuse 2 is for 24V control power rated at 5-Amps.

  • Page 83: Customer Custom Parameter Settings

    SECTION XI CUSTOMER CUSTOM PARAMETER SETTINGS This section is set aside for customer use where customer or specific parameters/settings can be documented, as programmed by them for their specific dryer. It is suggested that any parameter changes or customer cycles be documented here for future reference.
  • Page 84 PROGRAMMED CYCLE A-F: Cycle: ___________________ Cycle Type: AUTO Reverse Mode: ________________ (Option) Dry Temp: ______________________ Dry Level: ______________________ Cool Down Time: ______________________ Cool Down Temp: ______________________ Controlled Cool Down: ______________________ Cycle Type: MANUAL Reverse Mode: ________________ (Option) Dry Time: ______________________ Dry Temp: ______________________ Cool Down Time:...
  • Page 85 PROGRAMMED CYCLE 0-40: Cycle: ___________________ Cycle Type: AUTO Reverse Mode: ________________ (Option) Dry Temp: ______________________ Dry Level: ______________________ Cool Down Time: ______________________ Cool Down Temp: ______________________ Controlled Cool Down: ______________________ Cycle Type: MANUAL Reverse Mode: ________________ (Option) Dry Time: ______________________ Dry Temp: ______________________ Cool Down Time:...
  • Page 86 113162 1 - 12/23/02-25...
