INSTALLATION MANUAL
T18UTW-7-WIFI
INSTALLATION
MANUAL
T18UTW-7-WIFI
SASWELL CONTROL
www.saswell.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the T18UTW-7-WIFI and is the answer not in the manual?

Questions and answers

Mark Smith
July 14, 2025

My old thermostat had 7 wires and a wire terminal marked “E”. Does it hook to the “S” terminal? All of the other wire terminals are the same.
