Figure 3-2 Basic Screen - Acom 700S User Manual

e
g
b
c
d
1
The WARNING messages appear only temporarily (for about three seconds), afterwards the indication of
the operating values is restored automatically (see Section
The SOFT FAULT messages appear in the same field but they remain on the screen until the AUTO OPERATE
time is elapsed (see Section
the operating values (regime measurands) indication is restored too.
c) Working mode indicator - OPR, STB or AUTO OPER
(See Section
4.1 Change of Modes RX/TX and Operate/Stand-by; AUTO OPERATE user setting
d) RX/TX indicator
RX/TX indicator reads the request for transmit (KEY-IN input). The RX indication is green and the TX is red.
The indicator will flash frequently if switch over is impossible.
e) Forward power bar graph and digital readout
Displays the forward power fed into the antenna.
f) Reflected power bar graph and digital readout
Entering the red zone is not allowed.
g) PA transistor temperature bar graph and readout
Entering the red zone is not allowed.
Page 22 of 52 | S e c t i o n FIRST POWER-ON, CONTROL SYSTEM, AND INITIAL CHECK

Figure 3-2 Basic screen

4.1.c AUTO OPERATE user setting
User's Manual | ACOM 700S | 1.8-54 MHz Linear Amplifier
4.4.a) The first protection level - WARNING
) or until the operator pushes any button, then
f
a
i
h
2
).
)
May 2021
