e)
OPERATE ACCESS
When locked, the amplifier remains in Standby and cannot be switched to Operate unless unlocked in the
same menu. Passwords are not used – this is only a simple protection against possible child actions, or
involuntary switching to Operate mode. While locked, an attempt for entering Operate mode will result in a
message:
The other preference items don't need explanation.

Menu FAULTS LOG

5.5.
This function reads on the screen the information stored in the memory about the last 28 HARD FAULT
protection trips (see

Figure 5-6 Menu FAULTS LOG

downloaded in a plain-text format file through the RS-232 port and a computer using a standard terminal
emulating program (TTY). The RS-232 protocol settings are: 9600, 8 N 1.
Page 38 of 52 | S e c t i o n MENUS - SETTINGS AND OPTIONS
User's Manual | ACOM 700S | 1.8-54 MHz Linear Amplifier
"OPERATE MODE IS LOCKED"
). By pushing the FILE button, the information may be also
Figure 5-6 Menu FAULTS LOG
May 2021
