Menu AMP SERVICE (Amplifier Service Functions)

5.2.
The amplifier service menu (see
screen (see
Figure 5-1 MENU SELECTION
The AMP SERVICE menu is used for checking and adjustment of the zero-signal (idle)
drain current of the final transistors and for testing some functions and circuits of the
amplifier when serviced. We recommend these procedures are carried out only by a
trained service technician!
The necessary service function is selected with the buttons
SELECT buttons (left or right) the selected function is turned ON or OFF.
The inactive functions are greyed out and the active are red. When leaving a function submenu, it is turned
off and deactivated automatically. At pressing the EXIT button all service functions are turned off, and the
MENU SELECTION screen comes back (see
button, the basic screen returns (see
Page 34 of 52 | S e c t i o n MENUS - SETTINGS AND OPTIONS

Figure 5-3 Menu AMP SERVICE

) at RX mode only.
NOTICE
Figure 5-1 MENU SELECTION
Figure 3-2 Basic screen
Figure 5-3 Menu AMP SERVICE
User's Manual | ACOM 700S | 1.8-54 MHz Linear Amplifier
) is accessible from the MENU SELECTION
ITEM and ITEM
). At consecutive pushing of the EXIT
).
(up and down). With the
May 2021
