AES global StylusCOM Audio Manual page 4

StylusCOM – Slave Monitor Wiring Guide
Monitor Power Supply Distances:
CAT5 Cable – 8m
1.5mm Cable – 15m
(MAX DISTANCE BETWEEN MONITORS)
KEEP POWER CABLE BETWEEN MONITORS AS SHORT AS POSSIBLE – SEE
4 MONITORS
IN TOTAL :
1 MASTER
3 SLAVES
MASTER
PSU #2
(THE MASTER MONITOR MUST ALREADY BE SET UP BEFORE TESTING SLAVES)
Second power supply is used to power all
of the monitors indoors. Power between
monitors will be shared using 1.0mm
cable.
Wire the SLAVE OUT terminals to the SLAVE IN
MONITOR 4 terminals of the next monitor.
SLAVE OUT can also be split 2-ways as shown
in the diagram below.
SLAVE
MASTER
OUT
SLAVE OUT
DATA
AUDIO
SLAVE
GND
24v
0v
PSU #2
POWER CABLE ON PAGE 1
SLAVE
TO MONITOR 4
OUT
SLAVE OUT
SLAVE IN
DATA
AUDIO
GND
24v
0v
IN
SLAVE IN
SLAVE
OUT
SLAVE OUT
SLAVE IN
24v
0v
IN
DATA
AUDIO
GND
IN
DATA
AUDIO
GND
