Power And I/O Connector - Logic IO RTCU LX5 pro Technical Manual

RTCU LX5 pro Technical Manual V1.00
Advanced Industrial M2M/IoT Gateway

Power and I/O Connector

16 pin I/O connector overview
Pin Name
1 XPWR
2 DIN1/IGN
3 DIN2
4 DIN3
5 GND
6 CAN-H
7 AIN1
8 AIN3
9 XGND
10 DOUT1
11 DOUT2
12 DOUT3
13 DOUT4
14 CAN-L
15 AIN2
16 AGND
Logic IO ApS.
Holmboes Allé 14
8700 Horsens
Denmark
AIN3 8 16
AIN1 7 15
CAN-H 6 14
GND 5
DIN3 4 12
DIN2 3 11
DIN1 2 10
XPWR 1
Description
Power supply, positive (+) connection
Digital input 1 / Ignition input
Digital input 2
Digital input 3
System ground
CAN bus H-signal
Analog input 1
Analog input 3
Power Ground
Digital output 1
Digital output 2
Digital output 3
Digital output 4
CAN bus L-signal
Analog input 2
Analog Ground
Page 9 of 37
AGND
AIN2
CAN-L
13 DOUT4
DOUT3
DOUT2
DOUT1
9 XGND
