RTCU LX5 pro Technical Manual V1.00
Advanced Industrial M2M/IoT Gateway

ISM RF

The RTCU LX5 is provided with an ISM band RF radio that gives the device the ability to
communicate wirelessly with other certain types of equipment and devices. The radio
communicates in the 868 MHz frequency band and complies with the European EN 300 220
requirements. The antenna for the ISM radio is internal to the device.
Please consult the RTCU IDE on-line help for more information on how to configure the RF
interface.
In the table below, the specifications of the RF module is shown:
RF module specifications
Data
Output Power
Frequency
Modulation *
Baud Rate
Please note: Listen Before Talk (LBT)
the RF module. If the device is installed in an environment with disturbances in the same
frequency band, it can observe RF transmission difficulties.
•
Supported modulations are 2-FSK, 4-FSK, GFSK, MSK, ASK, and OOK.
1 LBT is a term used in radio communication whereby a radio transmitter senses its radio environment before it starts a transmission
Logic IO ApS.
Holmboes Allé 14
8700 Horsens
Denmark
Min.
-30 dBm
779 MHz
-
0.6 Kbaud
functionality to comply with EN 300 220 is implemented in
1
Page 24 of 37
Typ.
+10 dBm +12 dBm
869,4 MHz 928 MHz
GFSK -
38,4 Kbaud 600 Kbaud
Ph: (+45) 7625 0210
Fax: (+45) 7625 0211
Email: support@logicio.com
www.logicio.com
Max.
