1-Wire bus
The 1-Wire bus is available on the RJ45 communication connector. All 1-Wire communication goes
through a single connection, and all 1-Wire devices connected can retrieve power directly from the
bus (called parasitic power). For this, only two wires are needed – the 1-wire signal and the ground
reference – allowing minimal cable installations.
For 1-Wire ID-Button readers, which include a built-in LED, a dedicated output is available for this
purpose. Please consult the RTCU IDE documentation for further information.
RJ45 connector overview.
Pin
Name
7
1Wire
5
1W-LED
8
GND
Specification of the 1-Wire bus:
Total weight
1
1 The term of weight has been described in "Modular 1-wire concept – Technical Manual" document.
Logic IO ApS.
Holmboes Allé 14
8700 Horsens
Denmark
Description
1-Wire bus for ID-Button / Temperature sensor
1-Wire ID-Button LED
Signal Ground
Page 17 of 37
Max.
Unit
65
m
Email: support@logicio.com
Ph: (+45) 7625 0210
Fax: (+45) 7625 0211
www.logicio.com
