RTCU LX5 pro Technical Manual V1.00
Advanced Industrial M2M/IoT Gateway

LTE Cat. 4 Cellular Engine

The RTCU LX5 pro uses an LTE/UMTS/HSPA engine with the following features:
•
LTE Cat. 4 with a maximum of 150Mbps down / 50Mbps upload speed.
•
LTE-FDD: B1 / B3 / B5 / B7 / B8 / B20.
•
LTE-TDD: B38 / B40 / B41.
•
WCDMA: B1 / B5 / B8.
•
GSM: 900/1800 MHz
•
SMS (Text and PDU)
•
UMTS release 7, max. 42Mbps down / 5.76Mbps upload, (Cat 6)
•
Digitized audio / DTMF capability.
The Cellular Engine is designed for EMEA, Korea, and Thailand.

SIM-Card

The RTCU LX5 pro device contains a standard Mini SIM card reader located inside the device. The
SIM card reader is a lid-based reader with a mechanical lock system to secure the SIM card
installation. Please refer to Appendix A for the SIM card installation guide.
If the SIM-card is removed during the cellular operation, the device will be rejected from the
network shortly after.

WLAN

The RTCU LX5 pro device contains a radio for WLAN (Wi-Fi) communication.
WLAN Technical Data
•
Wi-Fi at 2.4 GHz ISM band
•
IEEE 801.11b/g/n/d/e/h/i
•
WPA/WPA2 certification
•
Up-to 150 Mbps
