Appendix D – Device Configuration Guide
Please refer to Appendix A to get inside access to the device.
The RTCU LX5 pro has many features, and some of them require configuration by using hardware
jumpers located inside the device. The placement of the jumpers are as follows:
Feature
Communication
Analog input
Logic IO ApS.
Holmboes Allé 14
8700 Horsens
Denmark
Analog input
jumpers
CAN bus
line termination
CAN bus
write enable
Jumper State
Installed
RS485 T.
Not installed
Installed
CAN T.
Not installed
Installed
CAN WE
Not installed
Installed
Ain 1
Not installed
Installed
Ain 2
Not installed
Installed
Ain 3
Not installed
Page 33 of 37
RS485 line
termination
Ain 3
Ain 2
Ain 1
Default state
RS485 line 120 Ω resistor enabled
RS485 line 120 Ω resistor disabled
CAN bus line 120 Ω resistor enabled
CAN bus line 120 Ω resistor disabled
CAN bus write-enabled
CAN bus write disabled
Ain 1 current mode selected
Ain 1 voltage mode selected
Ain 2 current mode selected
Ain 2 voltage mode selected
Ain 3 current mode selected
Ain 3 voltage mode selected
