3D movement sensor

The RTCU LX5 pro device contains a 3-axis accelerometer to detect vibration and motion. It makes
it possible to detect movement and position change in 3 directions, X-Y-Z with force as high as 16g
in acceleration. The most straightforward use is with the power management detecting when the
vehicle is moved and the most advanced analytical applications such as driving behavior/eco-
driving.
Please consult the RTCU IDE documentation for more detailed information.
The positions of the 3-axis are as following:
Specification:
Resolution ±16
Precision 12
Logic IO ApS.
Holmboes Allé 14
8700 Horsens
Denmark
Unit
g The acceleration can be set as relative to motion,
bit or relative to earth gravity
Page 18 of 37
+X
+Y
+Z
