Cabling; A) General Points; B) For Use In Audio; C) For Use In Video Calls - Intratone Intracode Visio Manual

See EEN-CIC12 guide: V233 - 5002 - XX
EEN-CIC12
+ - D+ D-
+
-
D+
A+
D-
A-
EEN-
M3G
V+ V-
G
A)
ENERAL POINTS
POWER SUPPLY: The central unit supplies power to the call panel via the + / - terminals.
CABLING: Twisted pairs – Diameter: 0.8 – Max. distance 100 metres.
Important note:
- The video function will only work if the call panel is installed with a 3G unit.
- If the call panel is installed with a PSTN line, only audio will work.
AUDIO
EEN-PICVIV1
VIDEO
EEN-PICVIV1
F AUDIO
B)
OR USE IN
Connect the following terminals up to the central unit:
Terminal
+ / -
D-+ / D-
A+ / A-
F VIDEO
C)
OR USE IN
Also connect the following terminals up to the V+ / V- (VIDEO 1) terminals on the
3G unit:
Terminal
V+ / V-
EN-V233 – 5003 – AB Installation and use of the EEN-PICV Intracode Visio call panel

CABLING

Power supply: 12 / 24 V – 2 to 4 A
Not supplied
+
EEN-M3G
+
EEN-M3G

CALLS ONLY

Detail NB pair
Power supply
Data
Audio
CALLS
Detail NB pair
Video
See EEN-CEN12 guide: V233-5001-XX
EEN-CEN12
+ - D+ D- A+ A-
+
-
D+
D-
A+
A-
EEN-
M3G
+
+
1
1
Twisted pairs
1
Twisted pair
1
V+ V-
or
THE CENTRAL UNITS
or
THE CENTRAL UNITS
recommended
MANDATORY
for video
