DIAGNOSIS IN THE EVENT OF A FAULT --------- 10 CERTIFICATE OF CONFORMITY -------------------- 11 : -------------------------------------------------------------------------- 11 TANDARDS : ------------------------------------------------------------------------- 12 ERTIFICATE EN-V233 – 5005 – AA Installation and use of built-in Visio call panel EEN-PIVIV3 Page 2 / 12...
Also connect the following terminals up to the V+ / V- (VIDEO 1) terminals on the 3G unit: Terminal Detail NB pair MANDATORY Twisted pair V+ / V- Video for video EN-V233 – 5005 – AA Installation and use of built-in Visio call panel EEN-PIVIV3 Page 5 / 12...
Connections in red refer to Visio (V+ / V-) Connections in black refer to (+ / - and D+ / D- and A+ / A-) EN-V233 – 5005 – AA Installation and use of built-in Visio call panel EEN-PIVIV3 Page 6 / 12...
This procedure is valid for 15 minutes per the timer. To exit from this procedure, wait until the timer finishes or exit from the "Settings on the panels" menu. EN-V233 – 5005 – AA Installation and use of built-in Visio call panel EEN-PIVIV3 Page 7 / 12...
Warning: the "door settings" menu will appear only if switches 4 / 5 / 6 on the EEN- CIC12 central unit are set to OFF. EN-V233 – 5005 – AA Installation and use of built-in Visio call panel EEN-PIVIV3 Page 8 / 12...
Remember to make a note of the serial number (7XXXXXX3) of the central unit. You will need this to go back into the installation and configure these settings on the keypad outside. EN-V233 – 5005 – AA Installation and use of built-in Visio call panel EEN-PIVIV3 Page 9 / 12...
Page 10
- Install a 3G unit instead of a GSM - The telephone does not one. support video Contact our technical support department (+33 (0)251 655 529) EN-V233 – 5005 – AA Installation and use of built-in Visio call panel EEN-PIVIV3 Page 10 / 12...
The panel and its accessories must not be disposed of with unsorted municipal waste but must be follow the WEEE (Waste Electrical and Electronic Equipment Directive) collection and recycling channel. EN-V233 – 5005 – AA Installation and use of built-in Visio call panel EEN-PIVIV3 Page 11 / 12...
