Before filling with water, remove the dust container
using the handle (VR2110).
Model VR2110 - Electrically operated water tank
c) Install the module:
Model VR2100: push the module horizontally along
the back of the robot. The module is installed in
place when you hear a "click" sound.
Model VR2110: insert the dust container into the
water tank and insert the handle into the slot. Then
press and hold the button in the centre of the tank
and push it horizontally along the back of the robot.
The module is installed in place when you hear
a "click" sound.
9. Removing the wiping module
Model VR2100: Once the robot has completed its work,
press the latches on both sides, remove the wiping
module backwards, empty the water from the water
tank and clean the cloth (do not move or flip the robot
during cleaning).
Model VR2100 - Hanging water tank
Model VR2110: Once the robot has completed its
work, press the button in the middle of the water tank,
remove the wiping module backwards, empty the
water from the water tank and clean the cloth (do not
move or flip the robot during cleaning).
Model VR2110 - Electrically operated water tank
10. Instructions for using the wiping module
80
• Do not use the wiping module unless supervised.
• For safety, make sure the wiping module is removed
when charging or when not in use.
• Do not attempt to wipe the carpet.
• For a better wiping effect, the wiping module should
be used after sweeping or vacuuming the floor three
times.
• To refill water or clean the cloth while the appliance
is operating, pause it, remove and reinsert the wiping
module as described in steps 8 and 9. Do not move or
flip the appliance to avoid positioning errors and map
loss.
• The wiping function of the appliance is designed for
wiping and aids deep cleaning. However, it cannot
effectively remove stubborn dirt and thus replace
human power.
USE
ON/OFF
Press and hold the button for 3 seconds, the indicator
light comes on and the appliance starts.
Press and hold the button for 3 seconds while the
appliance is in standby mode, the indicator light goes out
and the appliance switches off.
NOTE: The appliance cannot be switched off while it is
being charged.
CLEANING/PAUSE
After starting the appliance, briefly press the button
the appliance or start the appliance using the mobile app
(press any button to pause the appliance).
Note:
• The robotic vacuum cleaner cannot be used to remove
fluids.
• If the battery charge level is less than 20 %, the
appliance cannot operate. In this case, recharge it.
• If the battery charge level is less than 20 %, the
appliance automatically returns to the docking station.
• Before use, remove various wires (including the
docking station power cord) from the floor to prevent
outages and damage to objects or wires when the
robot catches these wires.
CHARGING
Automatic mode: The appliance automatically returns to
the docking station after work.
Manual mode: When paused, press the button
briefly
to start charging or you can use your mobile app to
charge the appliance. The indicator light flashes when the
appliance is fully charged.
Note: If the appliance does not find the docking station,
VR2110, VR2100
it will automatically return to its original position. In this
case, place the device manually into the docking station.
MAGNETIC STRIP
Magnetic strips can be set to separate areas that should
not be cleaned (for example, bathrooms, kitchens, etc.).
Note: attach the magnetic strip to the floor so that it
cannot move. Otherwise, it will affect its effectiveness.
CLEANING MODE
Upon start-up, the appliance will move according to the
cleaning program in curves to clean up the entire floor
area and complete the cleaning of all rooms one by one
in a regular, efficient manner with full coverage. When
cleaning is complete, the appliance returns to the docking
station and recharges automatically.
LOCAL CLEANING
By pressing and holding the button
robot is localized, cleans a circular area of 1.5 m diameter,
and automatically returns to its default location and stops
when cleaning is complete.
CLEANING PLANNING
You can set a fixed cleaning time using the mobile app.
The appliance will automatically start cleaning at the
specified time and will return to the docking station when
completed.
WI-FI RESET
If the mobile phone cannot connect to the appliance
due to a change in router and password configuration
or other reasons, press the button
on
for 3 seconds at the same time until you hear the "Wi-Fi
has been reset" voice prompt and until the indicator light
turns on blue-violet and flashes slowly.
SILENT MODE
You can turn robot voice messages on or off using the
mobile app.
SETTING THE SUCTION POWER
You can set the suction power to a quiet, standard or high
level using the mobile app.
When the carpet is detected, the suction force
automatically increases to the highest level. WARNING
- the carpet is correctly detected only with the Carpet
brush.
SETTING THE WATER FLOW (only for electrically
operated water tank of model VR2110)
You can set the water flow to a low, standard or high level
using the mobile app.
USING THE REMOTE CONTROL
VR2110, VR2100
1
2
3
4
for 3 seconds, the
5
1. Cleaning planning
2. Moving forward
3. Turning left
4. Local TURBO cleaning
5. Start/pause charging
6. Automatic cleaning / pause
7. Cleaning/pause
and the button
8. Turning right
9. Peripheral cleaning
10. Setting suction power / water flow
Note: To ensure that all the correct settings are effective,
you must point the remote control at the front of the
robotic vacuum cleaner from close proximity.
TIME SETTING
1. Press the button on the remote control to enter the
time setting, the Sunday symbol flashes on the LCD.
2. Press the left and right buttons to select the day of the
week and press the button
LCD will automatically switch to the clock setting.
3. Press the up and down buttons to set the hour and
press the left and right buttons to move to the minute
setting.
4. After setting the current time, point the remote control
at the front of the robotic vacuum cleaner and press
the button to confirm all time settings. Failure to
do so will invalidate your settings.
5. This completes the time setting for both the remote
control and the robotic vacuum cleaner.
Cleaning plan
EN
6
7
8
9
10
to confirm it, then the
