- Page 1 ERO Micro Beam FX LED Moving Head with SMD LED Effects Ring User Manual The information in this user manual is subject to change at any time without notice. Version: 1.0 Date of creation and author's initials: 07-10-2019 RV Revision date and author's initials: -...
- Page 2 'Box Contents' are included in the package. In the event that the Ayra ERO Micro Beam FX does not function properly, or if you have any issues while operating it, please remove the plug from the power socket and contact your retailer for assistance.
-
Page 3: Safety Instructions
Safety Instructions WARNING! Keep this device away from moisture, water and rain to avoid the chance of electric shocks! WARNING! Only connect this device to a suitable power socket. This device functions on a specific power voltage. If it is plugged into a power socket with a different voltage, it could result in permanent damage and even dangerous situations such as fire or electric shocks. - Page 4 - Should the device not be used in the manner described in this user manual, damages or even injuries could occur. Ayra cannot be held responsible for any injuries or damages that occur as a result of improper use of this product.
- Page 5 Suitable for indoor use only: this product was only designed for indoor use. The maximum environmental temperature must not exceed 40 degrees Celsius (104 degrees Fahrenheit). Contact: Ayra professional lighting products Verrijn Stuartweg 18 4462 GE Goes The Netherlands Please do not send any products to this correspondence address.
- Page 6 Operation Guidelines for this Device 1. LED Beam Output 2. LED Ring Output 3. LED Display with Menu buttons 4. DMX input via 3-pin XLR 5. DMX output via 3-pin XLR 6. IEC C14 power input with fuse compartment The information in this user manual is subject to change at any time without notice. Version: 1.0 Date of creation and author's initials: 07-10-2019 RV Revision date and author's initials: -...
- Page 7 Operation and Mounting To activate the device, plug it into a mains socket. Once it's connected to an active power source, it will turn on automatically. The device cannot be operated while it is still starting up. During the start-up process, the moving head will move to calibrate all step motors.
- Page 8 An explanation of all available functions can be found below: ADDR: With this function, you can determine the DMX start address of the device. Set it channel 001, and the device will respond to DMX channel 1. Set it to channel 003, then the device will respond to DMX channel 3 and so on.
- Page 9 TEST: When the device needs to be checked, use the ‘TEST’ function to test one or more devices at the same time. The device(s) shall continuously runs through a programme within which the LEDs are tested so that any deviations or defects can be easily detected. The device shall continue to repeat the programme until it is manually interrupted (when you switch the device to sound control, for example).
- Page 10 Operation Modes Please find a clear explanation of the differences between all available Operation Modes below and how they are affected by the menu functions listed above. Auto: In Auto Mode, you can select one of the Operation Modes in which the device is not dependent on external factors such as DMX signals, master signals or sound.
- Page 11 White 0-100% 000-255 14CH mode: Function Value Master Dimmer 0-100% 000-255 Strobe Fast to Slow 000-255 (fast to slow) 000-255 Pan Fine 000-255 Tilt 000-255 Tilt Fine 000-255 Pan-tilt Speed 000-255 (slow to fast) Red Beam 0-100% 000-255 Green Beam 0-100% 000-255 Blue Beam 0-100% 000-255...
-
Page 12: Installation And Connection Instructions
When you want to place the ERO Micro Beam FX in an upright position, make sure that the device is placed on a stable surface such as a table, DJ booth or bar. The ERO Micro Beam FX is not fitted with rubber feet to grip the ground and stabilise the device. - Page 13 Cleaning and maintenance Clean the exterior of this device on a monthly basis with a dry, or slightly damp microfibre cloth. Ensure that the device is unplugged before cleaning it. Check that all screws are intact and secured and tighten or replace them where needed. Check all metal parts of the device for any signs of corrosion.
- Page 14 DMX Lighting Troubleshooting If you have a problem with your DMX light effect, please consult the troubleshooting section for possible solutions. If, after consulting this section, the problem remains unresolved, please contact your retailer for more information and/or help. This troubleshooting section contains information on how to solve the most common DMX light effect problems, but it does not and cannot cover every eventuality.
- Page 15 Signal loss or interference in the Close the DMX circuit with a DMX circuit terminator or connect a booster after maximum 32 fixtures. The device is not reacting properly Incorrect DMX channel mode Check that the correct DMX to DMX commands channel mode is set The operation mode can not be The device is in Slave mode...
-
Page 16: Technical Specifications
Technical Specifications Features: - Compact LED beam moving head - Tight light 'beam' thanks to specially designed optics - 15W RGBW LED light source - Ambient SMD RGB LED ring - LED Display with Menu buttons - Diverse operation modes - Automatic mode with adjustable programmes and adjustable speed - Sound / Music-Controlled mode with adjustable sensitivity - Master / Slave...
