Port specification
Model
Port size
Straight piping without
flow adjustment valve
Rear piping without flow
adjustment valve
Straight piping with flow
adjustment valve
Rear piping with flow
adjustment valve
Fluid contact material
Output characteristics
Model
PFM510- -1
PFM525- -1
PFM550- -1
PFM511- -1
01
02
N01
Rc
Rc
NPT
1/8
1/4
1/8
95 g
105 g
135 g
145 g
LCP, PBT, brass (electroless nickel plating), HNBR (+fluorine coating),
FKM (+fluorine coating), silicone, Au, SUS304
Max. measurement flow
[L/min]
10
25
50
100
N02
F01
F02
C4
φ4
(5/32")
NPT
G
G
One-
1/4
1/8
1/4
touch
fitting
125 g
135 g
165 g
175 g
Model
PFM510- -2
PFM525- -2
PFM550- -2
PFM511- -2
-23-
C6
C8
N7
φ8
φ6
φ1/4
(5/16")
One-
One-
One-
touch
touch
touch
fitting
fitting
fitting
55 g
65 g
95 g
105g
Max. measurement flow
[L/min]
10
25
50
100
No.PF##-OMJ0016
