  • Page 1 Installation and user's manual ECON A1 IP x4 29343277en / - 43.06...
  • Page 2: Table Of Contents

    Contents General information Operation Technical Data Using the sauna Package contents General safety precautions Changing the temperature Assembly of the control unit Control unit switch Wall mounting Electrical connection Troubleshooting 2.2.1 Connecting the sauna oven 2.2.2 Connecting the sauna lamp Circuit diagram Connecting the sensor lines Terms of guarantee...
  • Page 3: General Safety Precautions

    1.3 General safety precautions 2 Assembly of the control unit 2.1 Wall mounting lThis device has not been designed for being used by persons (including Mount the control unit outside the sauna children) that are physically or mentally cabin only. The most practical mounting handicapped have sensory...
  • Page 4 threaded holes Please note: upper threaded hole If the sauna cabin is not equipped with electrical conduits, the electrical cables must be lead along the outside of the cabin, preferably in one of the recesses between the wood boards. Therefore, you have to mount the control unit farther away from the cabin wall, so you can lead the cables into the unit.
  • Page 5: Electrical Connection

    2.2 Electrical connection 2.2.1 Connecting the sauna oven The electrical connection can Warning: Always connect the only be carried out by an sauna oven's neutral conductor. approved electrician, observing the local energy supply company's guidelines and those of the VDE Assemble the sauna oven and the (German Electrical Association).
  • Page 6: Connecting The Sensor Lines

    sensor 2.3 Connecting the sensor lines board You should not install sensor and power supply lines together, or lead them through the same conduit. This can lead to interferences in the electronics, such as "fluttering" in the switch protectors. If it is absolutely necessary to install them together, or the wire is longer than 3m, you should use a shielded sensor line such as...
  • Page 7 On the pages that follow, we would like to familiarise you with the operations and features of your sauna control system. In each case the illustrations next to the text show the displays visible on the control unit. The symbol means that the relevant part of the display is flashing.
  • Page 8 3.1 Using the sauna Press the button to switch on the sauna heater. The display shows the the set temperature (factory setting 95° C). The green operating LED comes on and as long as the sauna heater is on, the red heating LED is also displayed.
  • Page 9 4 Changing the temperature In the following one we show, how you can stop the temperature of the Sauna your desires accordingly. Please take into consideration that these values can vary by a few degrees, depending on cabin configuration. For safety reasons the temperature is measured in the hottest area of the cabin above the oven.
  • Page 10 5 The control unit switch The control unit switch can be found on the Control unit switch top end of the unit. Using this switch, you can isolate the electronics from = unit the mains supply in case of a breakdown. switched Please note that operating the control unit switch returns all settings to the factory...
  • Page 11 7 Connection diagram Attention! Dear customer, according to the valid regulations, the electrical connection of the sauna heater and the control box has to be carried out through the specialist of an authorized electric shop. We would like to mention to the fact that in case of a warrenty claim, you are kindly requested to present a copy of the invoice of the executive electric...
  • Page 12 Outside of Germany please contact your specialist dealer in case of warranty claims. Direct warranty processing with our service Service Address: department is in this case not possible. EOS-Werke Günther GmbH Adolf-Weiß-Str. 43 35759 Driedorf-Germany Equipment start-up date: tel +49 (0)2775 82-240...
