- Page 1 I N N O V A T I V E S A U N A T E C H N O L O G Y Emotec D Emotec H Sauna control unit Installation and operation manual NOT FOR END CONSUMERS! Made in Germany Druck Nr.
-
Page 2: Table Of Contents
Temperature sensor ............................20 Humidity sensor .............................20 2nd temperature sensor (bench sensor) ....................20 Connection scheme overview (Emotec D and H) ..................21 Connection of the vaporizer ..........................22 Installation and connection of the humidty sensor .................22 Installation and connection of the 2nd temperature sensor ..............23 Setup (commissioning / first switching) .......................24... - Page 3 Setup level access and graphic user interface ..................37 Symbol description ............................38 Description of settings .......................... 39-40 Troubleshooting (error messages) ........................41 Main switch (Switch-off ) .............................42 Service address ..............................43 Warranty information ............................43 Handling procedures for return shipments (RMA) - details for all returns ........44...
-
Page 4: Scope Of Delivery
1 spare overheating protection fuse 5 rubber cable glands 10. 1 installation & operation manual, 1 operation manual (for end users) Accessories (optionally available): sensor ........item 94.5725 (only for Emotec D and H) Humidity sensor ......item 94.5726 (only for Emotec H) -
Page 5: Technical Data
Technical data Voltage (power supply): 400 V 3 N AC 50 Hz Switching capacity: max. 9 kW resistive load, may be extended with a power extension unit (LSG) Heating time limit: 6 h / 12 h / unlimited* Housing: plastic, shatter-resistant Display: TFT colour display 55 x 74 mm (3,5“... -
Page 6: General Information About Sauna Bathing
General information Dear customer You have purchased a high-quality technical Please check whether the unit has arrived in per- device with which you will have years of sauna fect condition. Any transport damages should be fun. This sauna control unit was designed and immediately reported to the freight forwarder inspected according to the current European delivering the goods or you should contact the... -
Page 7: General Safety Precautions
General safety precautions ature setting. The temperature can be held within operating parameters and This device can be used by children aged 8 a minimal temperature gradient inside upwards and by persons with physical, the bench area of the sauna cabin can be sensory, or mental disabilities, or who achieved only if unit is assembled correct- have inadequate experience and knowl-... - Page 8 When using control units that offer the possibility of external access (GSM-module, remote button, etc.) or time-delayed switching (preselection time, weekly timer, or similar) a trig- ger guard with covered heating unit is required. (cover protection type 1-5 or S-Guard). Attention! Dear customer, according to the valid regulations, the...
-
Page 9: Installation
Installation of the main electronic block The main electronic block (relay box) may be installed only outside sauna cabin. The recommen- ded places of installation are the outer sauna wall or a plant room (technical room). The installation on the sauna roof is also possible. If empty ducts for connection cable are already available, then they usually predetermine the installation position. - Page 10 3. Hang the housing on the central upper screw. Make sure that this screw stands out approx. 3 mm from the wall surface. If the connection cables shall be connected from the rear, knock out the corresponding openings in the housing and insert the supplied cable glands (rub- ber cable holders) into these openings.
-
Page 11: Control Panel - Location And Cable Connections
Control panel Cable connection Installation place Draw the connection cable from the relay box to the control panel. The control panel may only be mounted out- The connection cable may be laid only bet- side the sauna cabin. If ductwork is already ween the outer sauna wall and insulation layer provided for electrical installations then the to prevent overheating (Fig. -
Page 12: Control Panel - Flush-Mounted Installation
Flush-mounted instalation Wall aperture: Width 120 mm Height 117 mm Depth min. 20 mm Advice: Pay attention to the correct orientation of the housing base, the opening for con- necting cable should be at the bottom side as shown on fig. - Page 13 By wall paneling 15 - 30 mm turn the brackets around Fig. 10 By wall thickness > 30 mm Leave the brackets in original position and mount the housing through the mounting holes in the bottom using 4 screws. Use 4 screws appropriate to the wall material.
-
Page 14: Installation Of The Temperatur Sensor
Connection of sensor cables You should not install sensor and power supply lines together, or lead them through the same feedthrough. This can lead to interferences in the electronics, such as “fluttering” in the relays. Con- nect the cable shielding (if present) to ground in the control unit. Please observe that the following dimensions relate to the values stipulated during the unit in- spection acc. - Page 15 3. Lead the sensor cable (black) and the limiter cable (white) through the drilled hole and connect both cables to the main relay box as advised on page 20. 4. Connect the sensor cable to the sensor board according to fig. 16. Make sure the connections are correct.
-
Page 16: Electrical Connections
Electrical connection Sauna heater connection The electrical connections may only be car- ried out by a certified electrician in compli- ance with the guidelines of the local power Install the sauna heater and the vaporizer in supply company and applicable legal regu- front of the air intake according to the manu- lations (e.g. -
Page 17: Connection Of The Sauna Lighting
Sauna lamp connection Heating time limitation The maximal heating time may be limited with the jumper #5 on the main board of the relay The sauna lamp must have the protection box. The limitation may be set to 6 hours, 12 class of at least IPx4 and should be resistant to hours or to 98 h 59 min. -
Page 18: Installation Diagram And Terminal Block Overview
Installation diagram EMOTEC H Feuchtefühler Steckeranschluß Fühler humidity sensor Sensor plug connector Bankfühler/2nd Sensor Ofenfühler/Sensor reserviert Leistungsteil Sensorbus Main unit (relay box) Relais box Saunabus light L1 U S1 3 4 Leuchte/light Lüfter/fan Bedienteil Control panel Tableau de commande Wb PE Schaltlasterweiterung L1 L2 L3 LSG, optional... - Page 19 Installation diagram EMOTEC D Steckeranschluß Fühler Bankfühler Sensor plug connector 2nd Sensor Ofenfühler/Sensor reserviert Leistungsteil Sensorbus Main unit (relay box) RJ10 Relais box Saunabus RJ14 light L1 U S1 3 4 Leuchte/light Lüfter/fan Bedienteil Control panel Tableau de commande L1 L2 L3 P max.
-
Page 20: Temperature Sensor
Temperature sensor ! ATTENTION! Feuchtefühler humidity sensor Bankfühler Connecting a sensor to the sauna bus 2nd Sensor Ofenfühler Sensor connector (RJ14) may damage the sensor reserviert reserved and the main board of the control unit! Sensorbus The sensors are connected via RJ10 modular Saunabus plugs to one of the corresponding sensor bus RJ10 jacks on the mainboard of the relay box... -
Page 21: Connection Scheme Overview (Emotec D And H)
Overview - connections at Emotec D = optional EMOTEC D (STB) Erweiterungsmodule Extension modules Leistungsteil Bedienteil Modules (additifs) Main unit (relay box) Control panel Relais box Tableau de commande 6P4C <-> 4P4C 6P4C <-> 4P4C 400 V 3N AC 50 Hz... -
Page 22: Connection Of The Vaporizer
Fig. 19 shows standard vaporizer connection from (in humid operation (EOS models). EOS control units will detect wa- mode) to indicate humidity control as per rel- ter shortage if there is zero potential at the Wm ative air humidity. The humidity sensor will be terminal of the control unit. -
Page 23: Installation And Connection Of The 2Nd Temperature Sensor
Installation of the option- If the 2nd sensor is faulty the temperature will be controlled via the main sensor over the al 2 sensor heater. After the fault is rectified the 2nd sensor will be automatically detected and configured upon Place of installation: The 2nd sensor (bench the new start of the control unit. -
Page 24: Setup (Commissioning / First Switching)
Setup (commissioning / first switching) Using the control unit for the first time or after a reset The Emotec control unit offers a fast and intuitive setup upon the first switching or after a full system reset. Step 1 - set language Language Choose the required language for menu navigation by rotating the jog-dial knob and press shortly to confirm. - Page 25 20:51 Display in standby mode by Display in standby mode by dry (Finnish) sauna operation humid (Bi-O) sauna operation (Emotec D and H). (Emotec H only). Cabin light switched on. Cloud symbol appears to in- dicate the humid mode. Cabin light switched on.
-
Page 26: Operation
By Emotec H models (with enabled vaporizer) the symbol for a quick selection between the dry and humid sauna mode will be shown at the first place. Settings interface by Emotec H Settings interface by Emotec D or by Emo- tec H with disabled vaporizer. The symbol for dry or humid mode se- lection is shown as the 1st option. -
Page 27: Symbol Description (Main Navigation Menu)
Operation principle with a jog-dial knob Rotate the jog-dial knob to the left or right in order to reach a function. Press shortly on the jog-di- al knob to open this function. Rotate the jog-dial knob to change the value (changed value turns from white to green). -
Page 28: Symbol Description (Additional Settings)
Symbol description - extended settings „Extended settings“ submenu provides a range of additional functions, which normally need to be set only once or quite seldom. Select the symbol in the main menu und press shortly on the jog-dial to enter. Language Time Allows to set the language for the menu navi-... -
Page 29: Graphic User Interface
Graphic user interface (GUI) and the current climate conditions query Thanks to the modern graphic user interface you can quickly access all functions and make ne- cessary settings, as well as make a simple instant query for the current sauna climate condition. The symbols on the start screen may be displayed in different colours, in order to indicate the cur- rent operation status - e.g. -
Page 30: Operation And Settings (Main Functions)
Operation and program settings Sauna on / off Press the button on the control panel for approx. 3 seconds to switch the sauna on. The display will show active heating state (see previous page). The cabin light will be also switched on. To switch the sauna off press the button shortly. - Page 31 Please observe that with a humidity sensor the humidity rH [%] setting will depend on the preset temperature. For safety reasons only the values to the left and under the curve may be selected. For instance at 60°C temperature your can set up to 40% rel.
- Page 32 Timer Temperature Timer Timer (swith-on time pre-selection) The timer function allows you to have your sauna switched on automatical- ly with the desired climate condition at some time in the future. You have Auswahl two possible options: Select event Einzeltermin - single event (single time switching, not recurrent) 20:51 20:51...
- Page 33 sauna - for instance during peak-off times you may set the sauna to run at lower temperatures with re- duced energy consumption, so that it can then reach the full temperature faster at the main time of use. Now select the program (1 of 4) and press on the jog dial knob. Set the required start time (hours and minutes) - e.g.
-
Page 34: Operation And Settings (Additional Functions)
Extended settings The submenu „Extended settings“ allows you to make additional settings, which normally need to be set only once or very seldom. In the main navigation menu select the symbol and press on the jog dial shortly. Language Here you can set the language for the menu navigation and messaging system. Press on the lan- guage symbol, in the respective submenu select the required language and press on the jog dial shortly to confirm. - Page 35 pin code. Rotate the jog dial to select a number, press on the jog dial to confirm it and to jump to the next digit. After the 4 digit confirmation the control panel will return to the start screen and the unit is now locked.
- Page 36 Operation data Here you can check the important information concerning your control unit (sauna) operation. Firmware - allows to check the currently installed firmware version. Rotate the jog dial to switch between two possible parameters. „Panel Vx.xx“ - shows the firmware in control panel, „Mod-LS Vx.xx“...
-
Page 37: Service-Level (Setup And Settings)
Service- and Setup The Emotec D and H models provide an extensive set of features and tools for the setup and fine-tuning of the sauna equipment in order to match the specific sauna cabin situation. This set- up menu is protected with a PIN code and should not be accessible to the end users. -
Page 38: Symbol Description
Symbol description Service intervals Potential-free contact Intervals for servicing & maintenance. Enables or disables the potential-free contact switching function. Temperature adaptation Setting for the temperature offset +/- °C. Fan speed settings. Refilling time back Grace time to refill the vaporizer (only Emotec H) Exits and returns to the main menu. -
Page 39: Description Of Settings
Settings Service intervals Allows to set the intervals for servicing and maintenance. Upon expiry the control panel will re- mind the user for a short time upon every switching about the pending servicing. The end user can check the remaining time to the next servicing in the extended settings menu. This function allows as well to keep track of the total operation time of the sauna. - Page 40 (for EU located saunas) and the se- lection of the connected heater type (dry sauna heater or Bi-O heater with vaporizer). Hint: you can disable the vaporizer, the Emotec H model will then function as the Emotec D. Reset Allows you to reset the unit back to the factory default settings.
-
Page 41: Troubleshooting (Error Messages)
• Check cable connections and restart the control unit; if the fault persists, contact the dealer or EOS service. If any other unidentified error messages appear, please contact EOS service. Make sure to supply the serial number, fault details and other relevant information. -
Page 42: Main Switch (Switch-Off )
The device „Switch-off“ switch You will find the rocker switch on the left side of the main relay box. You can completely dis- connect the control unit from the mains using this switch. Attention! Parts of the printed cir- cuit board will still remain energized in the switched off condition! Risk of electric shock! Device’s main switch Device switched on... -
Page 43: Service Address
Outside of Germany please contact your spe- cialist dealer in case of warranty claims. Direct Service Address: warranty processing with our service depart- ment is in this case not possible. EOS Saunatechnik GmbH Schneiderstriesch 1 Equipment commissioning date: 35759 Driedorf, Germany Tel: +49 (0)2775 82-514... -
Page 44: Handling Procedures For Return Shipments (Rma) - Details For All Returns
Handling procedures for return shipments (RMA) - Details for all returns ! Dear customer we hope that you will be satisfied with the purchased EOS product. In the rear case if you may have a claim and will need to return a product, please follow the procedures specified below.
