- Page 1 EMOTEC DC 9000 Assembly and operating instruction Made in Germany IP x4 Druck Nr. 29344198en / -23.12...
-
Page 2: Table Of Contents
English Table of Contents Package contents ....................4 Optional connections: ..................4 Technical data ......................5 General information concerning sauna bathing ............6 General safety precautions ..................7 Assembly of the control unit ..................8 Wall mounting....................8 Electrical connection ....................9 Connecting the sauna oven ..................9 Connecting the sauna lamp ................10 Connecting a fan .....................10 Connecting a power control unit ..............10 Connecting a colored light ................10... - Page 3 Operation ......................16 Button functions ....................16 Symbol description ..................16 Initial unit switch-on ....................17 Preset parameters ...................18 Finnish sauna mode ..................18 Temperature display ..................18 Actual - target display ..................18 Heating time ....................18 To consider when programming: ................19 The keylock / hotel mode ..................20 Specialist section ....................21 F1 Setting the current time ................21 F5 Link color light options with heater .............22...
-
Page 4: Package Contents
Package contents (subject to change) Included with the control unit are: 1. An heater-sensor board with overheat shutoff protection, KTY-sensors with sensor housing , two 3x25 mm fastening screws and a 2,0 m long sensor cable, red and white. 2. A plastic bag with three 4 x 20 mm fastening screws. 3. -
Page 5: Technical Data
Technical data Nominal voltage: 400 V 3 N AC 50 Hz Switching load: max. 9 kW Ohm resistive load (AC1 - mode) device can be extended by connecting powered control units up to 36 kW Heating time limit: 6 hr, 12 hr or no heating time limit Display: Jumbo backlit LCD Protection class:... -
Page 6: General Information Concerning Sauna Bathing
General information concerning sauna bathing Dear customer, with purchase of this sauna control unit you For the cabin light use only light bulbs. Do opted for a superior quality, high-tech elec- not use fluorescent lamps, energy saving tronic device which was developed and ma- lamps and gas discharge lamps. -
Page 7: General Safety Precautions
General safety precautions • his device has not been designed for being • Please note the safety and installation in- used by persons (including children) that formation from the sauna oven manufac- are physically or mentally handicapped turer. or have sensory disabilities. Moreover, it •... -
Page 8: Assembly Of The Control Unit
Assembly of the control unit Wall mounting Mount the control unit outside the sauna cabin only. The most practical mounting point would be the wall area onto which the sauna oven is mounted on the inside, except on the outside of the cabin. If elec- trical conduits are present, mount the con- trol unit accordingly. -
Page 9: Electrical Connection
Electrical connection Connecting the sauna oven The electrical connection may only be done by a qualified electrical technician under authority of the regulations of the Assemble the sauna oven according to the local power supply company and those instructions provided by the manufacturer in of the VDE. -
Page 10: Connecting The Sauna Lamp
Connecting the sauna lamp Connecting the remote but- Only ohm resistive load, we recommend to use special bulbs like baking oven bulbs.Other bul- Details can be found in the remote button bs, like energy-saving-lamps can assembly instructions. destroy the control unit. Connecting a GSM module The sauna lamp must be weatherproof pro- tected (IPx4) and resistant to the ambient... -
Page 11: Installation Diagram
Installation diagram EmoLux = alternativ Emotec oder 400 V 3 N AC 50 Hz Terminal arrangement on the circuit board. 500 mA T Jumper S1 FAN LIGHT WM Nr. 1 Ub E G Nr. 2 TEMP.- L1 L2 L3 W WB TEMP.-SENSOR LIMITER H-SENSOR... -
Page 12: Sensor Connection
Sensor connection 142°C Nr. 2 Nr. 1 TEMP.- Ub E G TEMP.-SENSOR LIMITER H-SENSOR Connection of sauna heaters ≤ 9 kW max. 100 W max. 100 W S1 FAN LIGHT WM L1 L2 L3 W WB 400 V 3 N AC 50 Hz P max. -
Page 13: Connection Of Sauna Heaters > 9 Kw
Connection of sauna heaters > 9 kW max. 100 W max. 100 W S1 FAN LIGHT WM L1 L2 L3 W WB P max. 9 kW 400 V 3 N AC 50 Hz 400 V 3 N AC 50 Hz * For public installations without heating time limitation, the pilot light must be installed in the control room. -
Page 14: Connecting The Sensor Lines
Connecting the sensor lines 2. Drill a hole to lead the cable through, pre- ferably through the middle of one of the The connection cables to the temperature wooden boards. sensor and power supply cables shall NOT 3. Lead the sensor cable through the drilled be drawn together or lead through the same hole and attach it to the sensor line accor- conduit. -
Page 15: Installing The Optional Bench Sensor
Installing the optional se- If there is a problem with the bench sensor, a fault message will appear: cond temperature sensor (bench sensor) E 103 = Interruption of bench sensor circuit Installation location: The bench sensor is fixed to the ceiling of the rear reclining bench E 104 = Short-circuit of the bench sensor as described for the installation of the heater In this case, the sensor must be checked by... -
Page 16: Operation
Operation Button functions „ An/Aus „ „Licht „ „Funktion/ Mode„ „Ab „ „Auf „ Operating Lamp Program button Selection switch on - off on - off buttons Symbol description Time Heating (dry) Preselected time Ventilation function Heating time Coloured light Lamp Error message If the control box does not pick off voltage after closure, please check the position of... -
Page 17: Initial Unit Switch-On
Initial unit switch-on After you have checked all of the connections once again, connect the unit to the mains by switching on all fuses or the main switch. The time appears on the display. 20:03 If the display flashes, proceed as follows: 12:03 With the buttons "Ab "... -
Page 18: Preset Parameters
Preset parameters Finnish sauna mode After switching on, the display alternates 20:03 between showing the current time and the remaining heating time. 05:58 Temperature display During the heating phase plus approx. 15 min- utes, the thermometer symbol continues to fill. The control phase begins once the end tem- perature is reached. -
Page 19: To Consider When Programming
If the sauna bath should be finished before the pre-set limitation, press the "On/Off "but- ton. The On symbol on display will disappear 20:03 and only the current time will be displayed. The cabin light automatically switches off 30 minutes after the heating is off. You can switch the lighting off at any time using the "light "... -
Page 20: The Keylock / Hotel Mode
The keylock / hotel mode By activating the keylock / hotel mode, the sauna can only be switched on and off by the user. Changes to the individual parameters are not possible. To activate the keylock / hotel mode, press the "Mode", "... -
Page 21: Specialist Section
Operator level section F1 Setting the current time For clock time adjustment please press „Mode“ and „ “ button simultaneously. (The display will show „F1“ and the clock symbol.) Please confirm with the „Mode“ button. The clock symbol will start to blink. 20:03 Please choose the desired value with the „... -
Page 22: F5 Link Color Light Options With Heater
F5 Link colour light with the sauna heater You can make the colour light system switch on simultaneously with the heater. In order to link the colour light functions with the heater, press the "Mode" and the " " button at the same time ("F1" and the clock symbol appear on the display) and then the "... -
Page 23: F8 The Optional Bench Sensor
F8 The 2nd temperature sensor (bench sensor, optional) To activate or deactivate the bench sensor (for instance, after an upgrade or an error) please press „Mode“ and „ “ button syn- chron. (The display shows „F1“ and the clock sym- bol.) Afterwards press „... -
Page 24: F10 Reset Time From The Submenus
F10 Reset time from the submenus To set the reset time on submenus (the time after which the display automatically returns to the basic state), press the "Mode" and " " buttons at the same time ("F1" and the clock symbol appear on the display) and then the "... -
Page 25: Programming Levels
Programming levels P1 Starting with the time preselection With time preselection, you may preselect the start of your sauna unit within 24 hours. Always make sure that there are no objects on the sauna unit before the heating process begins. Risk of fire! In order to set the time preselection, please press the "Funktion/Mode"... -
Page 26: Deactivating The Time Preselection
Deactivating the time preselection In order to deactivate the time preselection, please press the "On/Off " button. Then the sauna heater will be switched on, By pressing the "On/Off " button again the sauna heater is switched on. P2 Heating time limitation This program step will only appear if the device has not been set for the "Wochentimer"... -
Page 27: Activation Of The Weekly Timer
P0 Week timer This program step will only appear if the device has been set for the "week timer" mode during installation. You can program up to 4 switching times (slots) for each day of the week in the week timer menu. The heating time for each slot can be between 30 minutes and 12 hours. -
Page 28: P1 Starting With Time Preselection In Weekly Timer Mode
P1 Heater switching with time preselection in week timer mode Always make sure that there are no objects on the sauna unit before the heating process begins. Risk of fire! In order to set the time preselection, please press the "Mode" key. The preselection symbol and "P1"... - Page 29 If the controller is running in humid mode (HCS 9003 series), the time set here is the to- tal time including the reheating time set in F2. If the heating time is set to the maximum value of 12 h, a 6 h pause will be added once this 12 h period has elapsed.
-
Page 30: P5 Temperature Setting
P5 Temperature setting Attention:Temperature range in dry sauna mode 30 - 110° C in humid mode 30 - 70° C* * only for controllers supporting dry & humid modes. The default temperature is set to 95°C for dry sauna operation and 60°C for humid operation. -
Page 31: P6 Programming Fan Operation
P6 Fan operation programming This control unit provides you the possibility to switch a ventilation fan (max. 100 W) and to set its speed in 3 stages. The default setting is „no fan“ mode. Only in afterheating operation after the humid mode the fan is switched at the maximum speed. -
Page 32: P7 Ability To Dim The Cubicle Lights
P7 Dimming of sauna cabin light Please note that this function may only be work in combination with incandescent bulbs, we recommend to use special heat resistant bulbs. No fluorescent (energy-saving) or gas discharge lamps may be used. The default light setting is 100%. You can dim the cabin light of your sauna to your preference. -
Page 33: Coloured Light (Optional)
Coloured light (optional) This programming option is only available if the coloured light module (item number 942761 / 944286 / 944834) has been installed. Before installing the coloured light module the control unit must be completely switched off the power supply. You have the option of operating a coloured light device in your sauna using the HCS 9003 control unit. - Page 34 When the coloured light is switched on the control unit screen also displays the flashing 20:03 coloured light icon. blue The coloured light icon indicates the segment for the colour that is currently lit. The colours are assigned as follows. green yellow If coloured light mode is to be switched off...
-
Page 35: P9 Setting The Time Interval For The Coloured Light
P9 Setting the time interval for the coloured light s e t x This programming option gives you the option of automatically setting the length of time each collour is on. The fefault is one minute. You can set on-time to between 1 and maximum 10 minutes.. For shining period adjustment please press „Mode“... -
Page 36: The Control Unit Switch (Switch-Off)
The control unit switch (Switch- C o n t r o l u n i t off) switch = unit swit- The control unit switch can be found on the ched on top end of the unit. Using this switch, you can isolate the electronics from the mains supply in case of a breakdown. -
Page 37: Error Display
Error display n order to provide an immediate diagnosis for any errors that may occur, the following errors can be determined via on-screen error codes. Error code Error description E100 –Temperature sensor fault (no signal) E101 – Temperature sensor short circuit E103 –... -
Page 38: Service Address
Service Address: Outside of Germany please contact your EOS Saunatechnik GmbH specialist dealer in case of warranty claims. Adolf-Weiß-Straße 43 Direct warranty processing with our service 35759 Driedorf-Mademühlen, Germany department is in this case not possible. -
Page 39: Handling Procedures For Return Shipments (Rma) - Details For All Returns
Handling procedures for return shipments (RMA) - Details for all returns ! Dear customer we hope that you will rejoice in the ordered articles. Just in case that you are not entirely contented as an exeption, please follow the procedures specified below.This enabling us to ensure a quick and smooth handling of the return shipment.
