DBu/E01

Locking/Unlocking Changes to Settings

Changes to the settings can be locked to prevent inad-
vertent changes being made.
BatType
Locked?
TxPower
Remote
Locked?
A small padlock symbol will appear on adjustment
screens when changes have been locked.
When changes are locked, several controls and actions
can still be used:
• Settings can still be unlocked
• Menus can still be browsed
• Programmable switch still works (Mute and On/Off)
• Power can still be turned off by using the power
menu or removing the batteries.

Restoring Default Settings

This is used to restore the factory settings.
Remote
Default
Locked?
settings
Default

KeyType

KeyType
The DBu receives an encryption via the IR port from a
key generating receiver. Begin by selecting a key type
in the receiver and generating a new key (key type is
labeled KEY POLICY in the DSQD receiver). Set
the matching KEY TYPE in the DBu and transfer the
key from the receiver (SYNC KEY) to the DBu via the
IR ports. A confirmation message will display on the
receiver display if the transfer is successful. The
transmitted audio will then be encrypted and can only
be listened to if the receiver has the matching encryp-
tion key.
The DBu has three options for encryption keys:
• Standard: This is the highest level of security.
The encryption keys are unique to the receiver and
there are only 256 keys available to be transferred
to a transmitter. The receiver tracks the number of
keys generated and the number of times each key
is transferred.
• Shared: There are an unlimited number of
shared keys available. Once generated by a receiv-
er and transferred to the DBu, the encryption key
is available to be shared (synced) by the DBu with
other transmitters/receivers via the IR port. When
a transmitter is set to this key type, a menu item
named SEND KEY is available to transfer the key to
another device.
10
Gain
Yes
No
-40 -20
No
Yes
• Universal: This is the most convenient encryp-
tion option available. All encryption-capable Lec-
trosonics transmitters and receivers contain the
Universal Key. The key does not have to be gener-
ated by a receiver. Simply set the DBu and a Lec-
rosonics receiver to Universal, and the encryption
is in place. This allows for convenient encryption
25
amongst multiple transmitters and receivers, but not
as secure as creating a unique key.
0
Remote
Locked?
Default
KeyType

WipeKey

This menu item is only available if Key Type is set to
Standard or Shared. Select Yes to wipe the current key
and enable the DBu to receive a new key.
Default
KeyType
WipeKey

SendKey

SendKey
This menu item is only available if Key Type is set to
Shared. Press Menu/Sel to sync the Encryption key to
another transmitter or receiver via the IR port.
Default
KeyType
WipeKey
SendKey
KeyType
Standard
WipeKey?
No
Yes
SendKey
Share:
