Automationdirect.com Productivity 1000 P1-15CDD2 Manual

Input Specifications
Inputs per Module
Rated Voltage
Operating Voltage Range
Input Current
Maximum Input Current
Input Impedance
Minimum ON Current
Maximum OFF Current
ON Voltage Level
OFF Voltage Level
OFF to ON, ON to OFF Response
Status Indicators
Commons
Output Specifications
Outputs per Module
Rated Voltage
Operating Voltage Range
Maximum Output Current
Minimum Load Current
Maximum Leakage Current
On Voltage Drop
Maximum Inrush Current
OFF to ON, ON to OFF Response
Status Indicators
Commons
Maximum Applicable Fuse
External Power Supply Required
Sales 800-633-0405
8 (sink/source)
12–24 VDC
10.2–26.4 VDC, Max 30VDC
8.4 mA @ 24VDC
10mA @ 26.4 VDC
3k:
1.4 mA
1mA
> 9VDC
< 4.5 VDC
2ms Maximum, 1ms Typical
Logic Side (8 points)
1 (8 points/common)
7 (sourcing)
12–24 VDC
10.2–28.8 VDC
1A per point
1mA
0.3 mA @ 28.8 VDC
0.2 VDC @ 1A
4A for 50ms, 6A for 10ms
0.5 ms
Logic Side (7 points)
1 (7 points/common)
8A
12–24 VDC (-15% / +20%) @ 22mA
P1-15CDD2 Input / Output
P1-15CDD2
The P1-15CDD2 Input/Output Module provides
eight 12–24 VDC inputs plus seven 12–24 VDC
C1
outputs that source up to 1A per output to
1
loads connected to ground for use with the
2
Productivity1000 system.
3
4
5
Input Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
6
Output Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . 1
7
Module Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
8
QR Code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Wiring Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
V+
Schematic & Wiring Diagram . . . . . . . . . . . . . . . . . . . . 3
1
General Specifications . . . . . . . . . . . . . . . . . . . . . . . . . 4
2
Terminal Block Specifications . . . . . . . . . . . . . . . . . . . . 4
3 Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
4
5
6
7
C2
12-24VDC
INPUT/OUTPUT
Terminal Block sold separately, (see wiring options on page 3).
Warranty: Thirty-day money-back guarantee. Two-year limited
replacement (See www.productivity1000.com for details).
www.productivity1000.com
1000
