Installation; Test Connection - DIODE LED AlphaTECH LED STRIP LIGHT Installation Manual

REQUIRED TOOLS
1
2
5
1. Phillips-head Screwdriver
2. Ruler (Recommended)
3. Wire Stripper (Recommended)
4. Mounting Channel, or (2) Mounting Clips per 12".
5. (2) Screws per Mounting Clip
CHANNEL SIDE VIEW

INSTALLATION

1
TURN POWER OFF AT CIRCUIT
BREAKER
SHOCK HAZARD! May result in serious
injury or death.
Turn power OFF at circuit breaker prior to
installation.
LED Strip Light INSTALLATION GUIDE
AlphaTECH
®
3 4
AlphaTECH
®
2
DETERMINE LOCATION TO INSTALL
COMPONENTS
Refer to SYSTEM DIAGRAMS
1) Class 2 Driver
WIRE GAUGE & VOLTAGE DROP
Ensure applicable wire is installed between driver, fixture,
and any controls in between. When choosing wire, factor in
voltage drop, amperage rating, and type (in-wall rated, wet
location rated, etc.)
Note: AlphaTECH
connections. Ensure Class 2 power supply is compatible with
connector prior to installation.
Bare Lead*
INSTALLATION (CONT.)
3

TEST CONNECTION

Prior to mounting, attach to Class 2 LED Driver, turn on power and
test connection to ensure system is operating properly. Turn off
power again before mounting.
4
MOUNT AlphaTECH
*Note: There are several ways to install AlphaTECH
Please follow one of the options listed below.
Indoor/Outdoor Installation (pg. 3)
1
Underwater/Pool Installation (pg. 4)
2
2 OF 8
LED STRIP LIGHT
INSTALLATION GUIDE
2) Control 3) Strip Light
Strip Light is available with the following
®
MIC Lead** DC Lead**
*Must be used for pool/spa applications.
**For use in non-waterproof applications only.
LED STRIP LIGHT
®
LED Strip Light.
®
IG121620-3.0
