IP69
DIMMABLE
SAFETY & WARNINGS
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
1. Install in accordance with national and local electrical code
regulations.
2. This product is intended to be installed and serviced by a
qualified, licensed electrician.
3. Do not modify or disassemble this product beyond instructions
or the warranty will be void.
4. Do not use if there is any damage to the fixture or wiring.
Inspect periodically.
5. Do not install in direct sunlight or damage to the LED phosphor
will occur.
6. Do not attempt to fix this product in the field.
7. Failure to follow safety warnings, and installation instructions
will void the warranty for this product.
LED Strip Light INSTALLATION GUIDE
AlphaTECH
®
®
SUBMERSIBLE
AlphaTECH
®
HANDLE PRODUCT WITH CARE!
DO NOT POWER STRIP
LIGHT WHILE ATTACHED TO
SPOOL OR TIGHTLY COILED.
DO NOT BEND LED STRIP LIGHT
ON A HORIZONTAL PLANE.
1 OF 8
LED STRIP LIGHT
INSTALLATION GUIDE
DO NOT FOLD, CREASE, OR
TWIST LED STRIP LIGHT.
12 in.
DO NOT BEND LED STRIP
LIGHT TO A DIAMETER LESS
THAN 12 INCHES.
IG121620-3.0
Advertisement
Table of Contents
Related Manuals for DIODE LED AlphaTECH LED STRIP LIGHT
Summary of Contents for DIODE LED AlphaTECH LED STRIP LIGHT
- Page 1 AlphaTECH LED STRIP LIGHT ® ® INSTALLATION GUIDE IP69 DIMMABLE SUBMERSIBLE SAFETY & WARNINGS HANDLE PRODUCT WITH CARE! READ AND FOLLOW ALL SAFETY INSTRUCTIONS 1. Install in accordance with national and local electrical code regulations. 2. This product is intended to be installed and serviced by a qualified, licensed electrician.
-
Page 2: Installation
AlphaTECH LED STRIP LIGHT ® INSTALLATION GUIDE REQUIRED TOOLS DETERMINE LOCATION TO INSTALL COMPONENTS Refer to SYSTEM DIAGRAMS 1) Class 2 Driver 2) Control 3) Strip Light WIRE GAUGE & VOLTAGE DROP Ensure applicable wire is installed between driver, fixture, and any controls in between. -
Page 3: Indoor/Outdoor Installation
AlphaTECH LED STRIP LIGHT ® INSTALLATION GUIDE INDOOR/OUTDOOR INSTALLATION Connect AlphaTECH LED Strip Light, then press ® UNDERWIRE CHANNEL firmly into channel. If necessary, include a small amount of silicone adhesive/sealant within the channel to hold it in place. *Note: Placing AlphaTECH LED Strip Light within another ®... -
Page 4: Mounting Clip
AlphaTECH LED STRIP LIGHT ® INSTALLATION GUIDE INDOOR/OUTDOOR INSTALLATION CHANNEL MOUNTING CLIP Screw mounting clip to surface *Note: Placing AlphaTECH LED Strip Light within another ® channel may not be necessary nor recommended. Press AlphaTECH LED Strip Light firmly into ®... - Page 5 Unlike concrete pools, most fiberglass and vinyl lined pools have strict warranty guidelines that do not allow the user to deface the pool wall surface. Diode LED does not recommend mounting to fiberglass or vinyl pool walls and/or defacing the surface in any way (ex.
- Page 6 AlphaTECH LED STRIP LIGHT ® INSTALLATION GUIDE INSTALLATION (CONT.) TROUBLESHOOTING ATTACH DRIVER AND LIGHTING • Ensure an appropriate gauge of Shift in CONTROL. wire is installed between strip light brightness and LED driver. See VOLTAGE and/or kelvin OUTDOOR/UNDERWATER INSTALLATION DROP CHARTS. Some LEDs •...
- Page 7 AlphaTECH LED STRIP LIGHT ® INSTALLATION GUIDE SYSTEM DIAGRAMS The following diagrams are provided as example system designs. For information regarding larger systems or systems not pictured below, please see our web page or contact technical support. Always review each component installation guide for detailed and up-to-date wiring instructions.
- Page 8 AlphaTECH LED STRIP LIGHT ® INSTALLATION GUIDE VOLTAGE DROP CHARTS For best performance and lumen output, ensure proper wire gauge is installed to compensate for voltage drop of low voltage circuits. Example: 24V Voltage Drop & Wire Length Distance Chart Determine load size.
