DIODE LED DI-TB-CONN-TT Series Installation Manual

DO NOT CONNECT
DRY LOCATION
TO HIGH VOLTAGE
QUICK SPECS / MODELS
SKU DI-TB-CONN-TT*
Max. Voltage
24V
Max. Amp 12V - 5A / 24V - 4A
Wire Gauge 16 AWG - 20 AWG
Ambient Temp †
-4° - 122°F (-20° - 50°C)
† Do not install product in environment outside listed
temperature.
SAFETY & WARNINGS
1. Install in accordance with national and local electrical
code regulations.
2. This product is intended to be installed and serviced by a
qualified, licensed electrician.
3. Do not modify or disassemble this product beyond
instructions or the warranty will be void.
4. Do not submerge, or install within 5 feet of a swimming
pool.
5. Failure to follow safety warnings, and installation
instructions will void the warranty for this product.
TAPE LIGHT TERMINAL BLOCK CONNECTOR INSTALLATION GUIDE
TAPE LIGHT TERMINAL BLOCK CONNECTOR
®
Tape-to-Tape
Front
Back
Tape-to-Wire
INSTALLATION (WIRE)
1
INSERT WIRE
Insert 16-20 AWG wire into terminals, observing polarity.
2
SECURE CONNECTION
Using phillips head screwdriver, fasten terminal screws
to secure wire in place.
1 OF 2
INSTALLATION GUIDE
Front
Back
-
+
-
+
IG111418-1.0
