DIODE LED LINAIRE FLEX TOP BEND Installation Manual

Advertisement

Quick Links

SAFETY & WARNINGS
1. Install in accordance with national and local electrical code regulations.
2. This product is intended to be installed and serviced by a qualified, licensed
electrician.
3. Do not modify product beyond instructions or warranty will be void.
4. Do not submerge, nor install within 5 feet of a swimming pool.
5. Only install with a compatible Listed Class 2 DC LED driver.
6. Do not exceed maximum run recommended for Tape Light.
7. Failure to follow safety warnings, and installation instructions will void the
warranty.
#
R
HANDLE WITH CARE
E
F!
Do not cover with any
materials.
Do not allow product
hang unsupported
during installation.
Installation Guide | LINAIRE® FLEX TOP BEND & SIDE BEND | 12182023 | V0.1
TRUE
1
1
1 of 3
WARNING
Do not power while
attached to spool or
tightly coiled.
Top Bend: Do not bend
on a horizontal plane.
LINAIRE® FLEX TOP BEND & SIDE BEND
Installation Guide
DO NOT CONNECT DIRECTLY TO LINE VOLTAGE POWER!
Read all warnings and installaion instructions thoroughly.
Do not bend to a
diameter less than 5
inches.
Side Bend: Do not bend
on a vertical plane.
Do not fold, crease, or
twist.
Black
TRUE
Final
Diode LED
Color
Black
