DAKE RATCHET LEVER ARBOR PRESS Model 3A INSTRUCTIONAL MANUAL WARNING! Read and understand all instructions and responsibilities before operating. Failure to follow safety instructions and labels could result in serious injury. Dake Corporation www.dakecorp.com Phone: 800.937.3253 724 Robbins Road customerservice@dakecorp.com Grand Haven, MI 49417 Fax: 800.846.3253...
Purchasers who notify Dake within the warranty period will be issued a Case number and/or a Return Material Authorization (RMA) number. If the item is to be returned per Dake’s request, the RMA number must be clearly written on the exterior packaging. Any item shipped to Dake without an RMA will not be processed.
Grand Haven, MI 49417 www.dakecorp.com RETURN & REFUND POLICY Thank you for purchasing from Dake! If you are not entirely satisfied with your purchase, we are here to help. Returns All Dake manufactured / distributed machines, parts and couplings include a 30-day return option. These policies are valid from the date of final shipment to the end user.
Dake Corporation 724 Robbins Road Grand Haven, MI 49417 www.dakecorp.com SPECIFICATIONS Model Largest arbor 4” Number 902004 Capacity over table 16” Capacity 5 tons Capacity over table plate 14-1/2” Leverage ration 55:1 Base length 24” Ram size 2 x 2 x 23”...
Dake Corporation 724 Robbins Road Grand Haven, MI 49417 www.dakecorp.com HANDLE POSITION CAUTION: NEVER PULL THE PRESS HANDLE PAST THE HORIZONTAL POSITION! To avoid personal injury and damaging the press only pull until the handle is horizontal, then return the handle back up as far as it allows before bringing the handle back down. This ensures that the pawl fully engages with the gear teeth to prevent tooth damage and gear slippage that can cause harm to the machine and worker.
Please contact factory for current prices. ORDERING INFORMATION Parts are available for direct purchase from Dake or through a distributor. When placing a parts order, you will need to provide the part number, name of part, and model number. All parts shipped F.O.B.
