DAKE HAND-OPERATED HYDRAULIC PRESS
WARNING!
Read and understand all instructions and responsibilities before operating. Failure to follow
safety instructions and labels could result in serious injury.
Dake Corporation
724 Robbins Road
Grand Haven, MI 49417
Model 25H
INSTRUCTIONAL MANUAL
Phone: 800.937.3253
Fax: 800.846.3253
www.dakecorp.com
customerservice@dakecorp.com

Advertisement

Table of Contents
loading

Related Manuals for Dake 25H

Summary of Contents for Dake 25H

  • Page 1 DAKE HAND-OPERATED HYDRAULIC PRESS Model 25H INSTRUCTIONAL MANUAL WARNING! Read and understand all instructions and responsibilities before operating. Failure to follow safety instructions and labels could result in serious injury. Dake Corporation www.dakecorp.com Phone: 800.937.3253 724 Robbins Road customerservice@dakecorp.com Grand Haven, MI 49417...

  • Page 2: Table Of Contents

    Dake Corporation 724 Robbins Road Grand Haven, MI 49417 www.dakecorp.com TABLE OF CONTENTS DAKE STANDARD LIMITED WARRANTY ............2 RETURN & REFUND POLICY ................3 SAFEGUARDING THE POINT OF OPERATION ..........4 SPECIFICATIONS ....................5 SAFETY ........................ 5 SET UP ......................... 7 FILLING PRESS WITH OIL ................

  • Page 3: Dake Standard Limited Warranty

    Purchasers who notify Dake within the warranty period will be issued a Case number and/or a Return Material Authorization (RMA) number. If the item is to be returned per Dake’s request, the RMA number must be clearly written on the exterior packaging. Any item shipped to Dake without an RMA will not be processed.

  • Page 4: Return & Refund Policy

    Grand Haven, MI 49417 www.dakecorp.com RETURN & REFUND POLICY Thank you for purchasing from Dake! If you are not entirely satisfied with your purchase, we are here to help. Returns All Dake manufactured / distributed machines, parts and couplings include a 30-day return option. These policies are valid from the date of final shipment to the end user.

  • Page 5: Safeguarding The Point Of Operation

    ANSI B11.2 - Hydraulic Power Presses - Safety Requirements for Construction, Care, and Use It is important that Dake press users have a clear understanding of their responsibility involving the care and use of their Dake hydraulic press, including point-of-operation safe guards. Dake strongly recommends that Dake press users obtain a copy of the current American National Standard Institute (ANSI) B11.2 standard, for a more complete understanding of their responsibilities.

  • Page 6: Specifications

    In the space provided record the serial number and model number of the machine. This information is only found on the black and gold Dake tag shown below. If contacting Dake this information must be provided to assist in identifying the specific machine.
  • Page 7 Dake Corporation 724 Robbins Road Grand Haven, MI 49417 www.dakecorp.com • This machine is intended to be operated by one person. This person should be conscious of the press ram movement not only for themselves but also for persons in the immediate area of the machine.

  • Page 8: Set Up

    FAILURE TO DO SO WILL CAUSE DAMAGE TO THE HOIST. b. If a tracking problem exists, contact the Dake factory for instructions. 6. Fasten nosepiece to the end of the screw using the thumbscrew included.

  • Page 9: Operation

    Dake Corporation 724 Robbins Road Grand Haven, MI 49417 www.dakecorp.com OPERATION CONTROLS Hand Crank: (items 57 & 58) on the side of the press is to assist in lowering and raising the table of the press once the table pins are removed. Do not forget to replace the pins once you have the table at the desired height.

  • Page 10: Troubleshooting

    Dake Corporation 724 Robbins Road Grand Haven, MI 49417 www.dakecorp.com TROUBLESHOOTING PUMP PACKING LEAKAGE If oil leaks past the pump packing, tighten the pump packing nut (item 9) until the pump handle moves with resistance, then slack off slightly to cause the handle to stay in position after being let go.

  • Page 11: Other Troubleshooting

    Dake Corporation 724 Robbins Road Grand Haven, MI 49417 www.dakecorp.com OTHER TROUBLESHOOTING SYMPTOM CAUSE SOLUTION Oil leaking from 1) Reservoir is over filled.* 1) Drain excess oil. piston oil seal. 2) Piston Packing is worn or 2) Replace Piston Packing.

  • Page 12: Exploded View & Parts List

    Dake Corporation 724 Robbins Road Grand Haven, MI 49417 www.dakecorp.com EXPLODED VIEW & PARTS LIST HAND PUMP ASSEMBLY Item Item Part Part Name Part No. Qty Part Name Pump Body Pump Plunger Ball Valve Handle Socket Pin 594A Hex Cap Screw...
  • Page 13 Dake Corporation 724 Robbins Road Grand Haven, MI 49417 www.dakecorp.com WORKHEAD ASSEMBLY Item Part Item Part Part Name Part Name Piston Bumper Cylinder Gasket Cylinder Clamp Ring Screw Handwheel 716518 Piston Leather (Serial No. < 192522) Screw Packing Ring Screw Nose 17976 (Serial No.
  • Page 14 Dake Corporation 724 Robbins Road Grand Haven, MI 49417 www.dakecorp.com GENERAL ASSEMBLY REV082018...
  • Page 15 Dake Corporation 724 Robbins Road Grand Haven, MI 49417 www.dakecorp.com GENERAL ASSEMBLY PARTS LIST Item Item Part Name Part No. Qty Part Name Part No. Hand Gauge 71265 Table Spacer 86487 Special Bushing 81384 Screw (3/8”-16 x 6”) 43341 Tube Fitting (37°) 1252 Lock Washer (3/8”)

  • Page 16: Ordering Information

    Please contact factory for current prices. ORDERING INFORMATION Parts are available for direct purchase from Dake or through a distributor. When placing a parts order, you will need to provide the part number, name of part, and model number. All parts shipped F.O.B.
