Worth Data 7100 RF Terminal Series Owner's Manual page 26

DataBar / RSS-14 plus UCC-128 Format
By default, DataBar / RSS-14 is disabled. Press the 1 key to toggle through the DataBar / RSS-14 options listed above. We support the
standard and stacked version of DataBar / RSS-14.
For more information on GS1 DataBar, see the GS1.org website at
Other Bar Code Options
Storage Tek Label
LabelCode 5
LabelCode 4
Bar Code IDs
The Storage Tek Tape Label code is a proprietary variation of Code 39 code used for the storage of computer data tapes. Enabling
the tape label code does not disable reading of Code 128 or Code 39 bar codes.
LabelCode 5 and LabelCode 4 are proprietary bar code types used by Follet.
Bar Code ID's are characters assigned to each bar code type to identify that particular type of code. These Bar Code IDs can out-
put as prefix to the bar code data to identify what type of bar code you are using. The Bar Code ID's are assigned as follows:
Bar Code ID
Codabar
Code 39
UPC-A
EAN-13
I 2of 5
2D Bar Code Setup
Note: The 2D options will only appear on LT712x models.
PDF 417
MicroPDF 417
Codablock F
Data Matrix ECC 140
Data Matrix ECC 200
Aztec Code
Aztec Runes
QR Code
Micro QR
Maxi Code
2D RF Terminals also have POSTNET and INTELLIGENT MAIL (IMBC) added to the 1D setup menu.
2D RF Terminals also have the ability to scan NEGATIVE bar codes under OTHER OPTIONS.
http://www.gs1.org/productssolutions/barcodes/databar/
ON
ON
ON
ON
Bar Code ID Bar Code
a 2 of 5 f UPC-E (1)
b Code 128 g EAN-8
c Code 93 i RSS-14
d MSI j StorageTek
e UPC-E(0) n Plessey
The ID character is transmitted in front of the bar code data.
ON
ON
ON
ON
ON
ON
ON
ON
ON
ON
ON OFF 1
OFF 2
OFF 3
OFF 4
OFF 5
ID Bar Code
o LabelCode 4
p LabelCode 5
r
s
x
OFF 1
OFF 2
OFF 3
OFF 4
OFF 5
OFF 6
OFF 7
OFF 8
OFF 9
OFF A
21
ID
y
z
