Chapter 2:
RF Terminal Setup
The RF Terminal can be configured using the Terminal Setup Menu. Most users do not need to change anything in the setup. The
most commonly changed setup parameters are the Terminal ID (especially if you have more than 1 terminal) and the Channel (if
you are adding an additional Base station).
Factory Default 1D RF Terminal Configuration
Factory Default 2D RF Terminal Configuration (In addition to 1D above)
Parameter Default Setting
RF Configuration RF Channel - 0
Terminal ID - 0
Security code - OFF
Skip opening screen - OFF
Control Keys Only - OFF
Auto Check Back - 00
Code 3 of 9 Code 39 - ON
Full ASCII - ON
Accumulate Mode - ON
Transmit Start Stop - OFF
MOD 43 Check Digit - OFF
Transmit MOD 43 - OFF
Caps lock - OFF
Decode Option - 0
2 of 5 Code Interleaved 2 of 5 - OFF
Check Digit - OFF
Transmit Check Digit - OFF
Standard 2 of 5 - OFF
2 of 5 Length - 06
UPC-A EAN 13 UPC/EAN ALL - ON
Supplements - OFF
UPC-A NSC - ON
UPC-A check digit transmit-
ted - ON
EAN-13 country code
transmitted - ON
UPC-E EAN 8
EAN-13 Check - ON
ISBN EAN-13 mode - OFF
UPC-A as EAN-13 - OFF
UPC-E First Char - OFF
EAN-8 First Char - ON
UPC-E Check Digit - OFF
EAN-8 Check Digit - ON
UPC-E Expanded Trans-
mission - OFF
UPC-E1 - OFF
Storage Tek Label – OFF
Other Bar Code
Options
LabelCode 5 - OFF
LabelCode 4 - OFF
Barcode IDs - OFF
PDF 417 - ON
Micro PDF 417 - ON
Codablock F - OFF
Data Matrix ECC-140 - OFF
Data Matrix ECC-200 – ON
(1D) POSTNET – OFF
NEGATIVE BARCODE - OFF
Parameter Default Setting
MSI /Plessey Code MSI - OFF
MSI with 1 mod 10 - OFF
MSI with 2 mod 10 - OFF
MSI with mod 11/mod 10 -
OFF
Transmit check digit - 0
Plessey - OFF
Codabar
Codabar - OFF
CLSI format - OFF
START STOP Char - OFF
Code 128 Code 128 - ON
UCC/EAN-128 - OFF
Databar / RSS-14 Databar / RSS-14 - OFF
Code 93 / Code 11 Code 93 - OFF
Code 93 full ASCII - ON
Code 11 - OFF
Code 11 Check Trans - 0
Bluetooth Settings Optional Feature
Bluetooth Device List
PIN - none
Time & Date Settings
Date Format - USA
Year Output – 2 digits
Shut Down Time – 5 min
Speaker Options Beep Volume - medium
Beep Tone - 2
Voice Volume - medium
Keypad Tone - ON
Laser Options
Double Decode - OFF
4.5 Second Beam - OFF
Aiming Dot Duration – 0
seconds
LCD Settings
4/6 Line Legacy Mode -OFF
Background Color – 1 (black)
Text Color – 2 (blue)
Brightness – medium
Brightness Timeout – 5 sec
Aztec Code - ON
Aztec Runes - OFF
QR Code - ON
Micro QR - ON
Maxi Code - ON
(1D) INTELLIGENT MAIL - OFF
