IMPORTANT
Carefully remove all the parts from the carton and
place them individually on a soft cloth to prevent
scratches or other damage.
Carefully and strictly follow these assembly instructions
to ensure a completed product as designed.
Do not use power tools above 8 volts to assemble.
Part List
H.
Side Panel
2 pcs.
F.
Shelf
1 pc.
Hardware List
Cam Lock Screw
46 pcs. (+2 extra)
Cam Lock
46 pcs. (+6 extra)
Carton 20 08000 0931 is also needed for assembly.
Tool(s) required for assembly: Phillips screwdriver, Level
Home Styles Customer Service: www.homestyles-furniture.com,
servicedesk@homestyles-furniture.com,
20 08000 0932
Kitchen Island
M3.5x64
M3.5x38
Wood Screw for Base
Wood Screw
12 pcs. (+1 extra)
10 pcs. (+1 extra)
M3.5x14
Dowel
Wood Screw for Hinge
36 pcs. (+1 extra)
48 pcs. (+1 extra)
I.
Side Panel
2 pcs.
G.
Shelf
4 pcs.
888-680-7460, 877-831-0319
J.
Side Panel
2 pcs.
L.
Drawer
1 pc.
Refer to later page(s) of these
instructions for drawer assembly.
Plastic Cap
16 pcs. (+1 extra)
Hinge
Adjustable Pin
8 pcs.
20 pcs. (+1 extra)
