IMPORTANT
Carefully remove all the parts from the carton and
place them individually on a soft cloth to prevent
scratches or other damage.
Carefully and strictly follow these assembly instructions
to ensure a completed product as designed.
Do not use power tools above 8 volts to assemble.
Part List
Hardware List
Hex Wrench
Cam Lock Screw
1 pc.
8 pcs. (+1 extra)
Small Hex Wrench
Cam Lock
1 pc.
8 pcs. (+2 extra)
Carton 20 05523 0932 is also needed for assembly.
Tool(s) required for assembly: Phillips screwdriver, Level
Home Styles Customer Service: www.homestyles-furniture.com,
servicedesk@homestyles-furniture.com,
20 05523 0931
Kitchen Island
A.
Top
1 pc.
M6x35
Head Cap Bolt
Cross Dowel
12 pcs. (+1 extra)
4 pcs. (+1 extra)
Adjustable Pin
4 pcs. (+1 extra)
Flat Washer
Spring Washer
8 pcs. (+1 extra)
8 pcs. (+1 extra)
M4x20
Machine Screw
Knob
8 pcs.
4 pcs.
888-680-7460, 877-831-0319
M6x50
Head Cap Bolt (long)
12 pcs. (+1 extra)
Handle
2 pcs.
Advertisement
Table of Contents
Related Manuals for Homestyles Kitchen Island 20 05523 0931
Summary of Contents for Homestyles Kitchen Island 20 05523 0931
- Page 1 1 pc. 8 pcs. (+2 extra) 4 pcs. (+1 extra) 8 pcs. 4 pcs. 2 pcs. Carton 20 05523 0932 is also needed for assembly. Tool(s) required for assembly: Phillips screwdriver, Level Home Styles Customer Service: www.homestyles-furniture.com, servicedesk@homestyles-furniture.com, 888-680-7460, 877-831-0319...
- Page 2 Assembly Instructions 2/6 IMPORTANT Ÿ Use a soft cloth between these parts and the floor. Ÿ Do not use power tools above 8 volts to assemble. Ÿ Do not tighten all the bolts until each part is properly assembled. Ÿ The unit must be level to work properly.
- Page 3 Assembly Instructions 3/6 STEP 3 Attach Side Panels (D) to Rails (H) with Cam Locks. (See Figure 2) Cam Lock Attach unit to Top (A) with Cam Locks. Figure 2 Head Cap Bolt STEP 4 Attach Stretchers (G) to Posts (E) and (F) with Head Cap Bolts.
- Page 4 Assembly Instructions 4/6 Head Cap Bolt STEP 5 Attach Shelves (I) to unit from Step 3. Attach post units to unit with Head Cap Bolts. Head Cap Bolt (long) Head Cap Bolt STEP 6 Attach Base (B) to unit with Cross Dowels, Head Cap Bolts (long) and Head Cap Bolts.
- Page 5 Assembly Instructions 5/6 Head Cap Bolt (long) STEP 7 Spring Washer Flat Washer Attach Feet (C) to unit with Flat Washers, Spring Washers and Head Cap Bolts (long). (See Figure 5) Figure 5 STEP 8 Turn unit over to its upright position. Insert Adjustable Pins into side panels at desired level.
- Page 6 Assembly Instructions 6/6 Machine Screw Handle STEP 9 Attach Handles to drawer with Machine Screws. STEP 10 Slide drawer into position. Level unit by adjusting the adjustable levelers on bottom of unit. (See Figure 8) Note: Unit must be level to work properly. Figure 8...
- Page 7 Home Styles is under no obligation to provide replacement parts. Parts are not available for fully assembled items nor are parts available for sale. Replacements for missing or damaged hardware or parts may be requested at: www.homestyles-furniture.com/customer-service/replacement-parts Home Styles Customer Service: www.homestyles-furniture.com, servicedesk@homestyles-furniture.com, 888-680-7460, 877-831-0319...
