Homestyles 20 05170 6512 Assembly Instructions Manual

Homestyles 20 05170 6512 Assembly Instructions Manual

Buffet

Advertisement

Quick Links

IMPORTANT
Carefully remove all the parts from the carton and
place them individually on a soft cloth to prevent
scratches or other damage.
Carefully and strictly follow these assembly instructions
to ensure a completed product as designed.
Do not use power tools above 8 volts to assemble.
Part List
G.
Bottom
1 pc.
K.
Door
1 pc.
Hardware List
Cam Lock
18 pcs.(+1 extra)
Cam Lock Screw
18 pcs.(+1 extra)
Carton 20 05170 6511 is also needed for assembly.
Tool(s) required for assembly: Phillips screwdriver, Drill (8 volts or less), 3/8" Drill Bit
Home Styles Customer Service: www.homestyles-furniture.com,
servicedesk@homestyles-furniture.com,
20 05170 6512
Buffet
L.
Door
1 pc.
Magnet
2 pcs.
Adjustable Pin
24 pcs. (+1 extra)
M.
Middle Panel
2 pcs.
M3.5x16
Wood Screw for Magnet
4 pcs. (+1 extra)
M3.5x16
Wood Screw
12 pcs. (+1 extra)
888-680-7460, 877-831-0319
H.
Back Panel
1 pc.
I.
Back Rail
2 pcs.
J.
Back Rail
1 pc.
N.
Shelf
4 pcs.
M4x25
Machine Screw
2 pcs.
Knob
2 pcs.

Advertisement

loading
Need help?

Need help?

Do you have a question about the 20 05170 6512 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Homestyles 20 05170 6512

  • Page 1 24 pcs. (+1 extra) 12 pcs. (+1 extra) 2 pcs. Carton 20 05170 6511 is also needed for assembly. Tool(s) required for assembly: Phillips screwdriver, Drill (8 volts or less), 3/8” Drill Bit Home Styles Customer Service: www.homestyles-furniture.com, servicedesk@homestyles-furniture.com, 888-680-7460, 877-831-0319...
  • Page 2 Assembly Instructions 2/6 IMPORTANT Ÿ Use a soft cloth between these parts and the floor. Ÿ Do not use power tools above 8 volts to assemble. Ÿ Do not tighten all the bolts until each part is properly assembled. Ÿ The unit must be level to work properly.
  • Page 3 Assembly Instructions 3/6 STEP 3 Wood Screw for Magnet Magnet Attach Magnets to Shelf (E) with Wood Screws for Magnet into pre-drilled holes. (See Figure 3) Figure 3 Cam Lock STEP 4 Attach Shelf (E) to unit with Cam Locks. Cam Lock STEP 5 Attach Side Panel (C) to unit with Cam Locks.
  • Page 4 Assembly Instructions 4/6 Cam Lock STEP 6 Attach Middle Panels (M) to unit. Attach Bottom (G) to unit with Cam Locks. Cam Lock STEP 7 Attach Top (A) to unit with Cam Locks.
  • Page 5 Assembly Instructions 5/6 STEP 8 Insert Adjustable Pins into side panels and middle panels at desired level. Place Shelves (D) and (N) into position. Attach Doors (K) and (L) to unit by sliding door hinges into side panel hinges. (See Figure 4) Attach Knobs to Doors (K) Adjustable Pin and (L) with Machine Screws.
  • Page 6: Hardware List

    Assembly Instructions 6/6 IMPORTANT Ÿ To help reduce the risk of the unit tipping over, the Tip-over Restraint must be installed following these instructions exactly. STEP 10 Anchor in wall Wall Screw Pre-drilled hole Bracket on wall at top of unit Place unit at desired location.
  • Page 7 Home Styles is under no obligation to provide replacement parts. Parts are not available for fully assembled items nor are parts available for sale. Replacements for missing or damaged hardware or parts may be requested at: www.homestyles-furniture.com/customer-service/replacement-parts Home Styles Customer Service: www.homestyles-furniture.com, servicedesk@homestyles-furniture.com, 888-680-7460, 877-831-0319...
