as below picture.
User can set Spot-Monitor output and sequence dwell time in this menu as well as OSD show/no-show.
Alpha blending is the transparency level of the menu screen. 0% means no transparency at all.
"VGA Display" is to get the proper edge alignment of display video depending on the monitor to be used, VGA or CCTV
monitor. In case that edge part of display video is cut off on the monitor (VGA or CCTV monitor), then try to change the
setting of "VGA Display" by checking/unchecking.
The position of icon is changed depending on the "VGA Display" setting.
[VGA Display is checked]
Note
DVR support following video resolutions: 640x480, 800x600, 1024x768 and 1280x1024.
User must to set the proper resolution according to the monitor resolution.
[VGA Display is not checked]
34
