Digital Watchdog VMAX User Manual page 11

No. Name
1 Video-In
2 Audio-In
3 Audio-Out
4 Video-Out
5 Spot-Out
6 VGA-Out
7 USB Port
8 LAN Port
9 NTSC/PAL Switch
10 RS-485 Port
11 Sensor Input
12 Alarm Output
13 Power Input
14 Grounding Terminal
Note Carefully check whether the specification of the peripheral devices matches the
2.2.1. Video-In
To connect the camera input to the corresponding channel marked on rear panel.
Note Camera Input voltage level is 1Vp-p±10%.
2.2.2. Audio-In
To connect audio input
2.2.3. Audio-Out
To connect audio output
Note Use of audio output with an amplifier is recommended
2.2.4. Video-Out
To connect composite monitor
2.2.5. Spot-Out
The spot monitor can be used to display input images in automatic switching mode.
2.2.6. VGA-Out
To connect a VGA Monitor.
2.2.7. USB Port (Version 2.0)
1) To backup recorded Video by using USB storage device (USB Memory Stick or USB HDD).
2) Firmware upgrade
3) To connect a mouse for system navigation
2.2.8. LAN Port
To connect RJ-45 jack of LAN cable. Consult network administrator or the internet provider for proper network setting.
2.2.9. NTSC / PAL Selection
Turn off the power of DVR and select the NTSC/PAL switch correctly. Then turn on the power again.
Camera. (Supports NTSC/PAL)
Audio input device (with amplifier)
Audio output device (with amplifier)
Composite Monitor
Composite Spot Monitor
VGA Monitor
USB port (Ver 2.0) for mouse operation or Image backup
10/100 Ethernet connection terminal
Select the video signal type
PTZ camera or external keyboard
Sensor input
Alarm output
Power supply connection (Default : 12 V, 5~8A)
Ground connection
Description
DVR's specification.
