3.4

Freeze Mode

Press FREEZE button on the front panel or click the right button on the mouse and select the Freeze mode while viewing a
live image, the image then pauses, but the date/ time information does not, and the system clock continues running. Press
FREEZE to pause the live view; press FREEZE again or click the right button on the mouse and select the FREEZE again
to resume the live view.
3.5

Call Monitor Operation

Press the CALL MON button on the front panel or click the right button on the mouse and select the CALL MONITOR in
order to enter call monitor control mode. The numeric panel will pop up at the center of the screen.
Click the specific channel button on the numeric panel to display full screen mode out of assigned spot out channels.
▪ Press the close button on the bottom of the numeric panel, it goes back to the previously programmed spot monitor
mode.
20
