15
3.2.2. Icons
The live mode display, icons or messages will be indicated on the screen to
Below are the icon categories, which are indicated on the monitor.
Icon to be shown
at right-upper corner on each channel screen
Continuous Recording
Motion Detection Recording
Sensor Activating Recording
Continuous+ Motion Recording
Continuous + Sensor Activating
Recording
Motion Detection + Sensor Activating
Recording
Emergency Recording
Sensor Activated
Motion Detected
Audio Channel
PTZ Camera
User can place USB mouse pointer in the bottom of the monitor
appeared as
shown
below.
indicate
the system mode or status.
Icon to be shown
At right-bottom corner on full screen.
No HDD, Smart Alarm & HDD Failure
Using Emergency Recording
Using PTZ
Warning for exceeding temperature
Showing sequence mode
Showing digital zoom mode
during
live mode. Then menu bar will be instantly
