PART IDENTIFICATION CHART

Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each
drawing is the key number of the part, from the PART LIST near the end of this manual. The number following
the key number is the quantity needed for assembly. Note: If a part is not in the hardware kit, check to see
whether it has been preassembled. Extra parts may be included.
M4 x 16mm
M4 x 16mm M4 x 22mm
M8 Locknut
Flat Head
Screw (72)–4 Screw (84)–6
(43)–2
Screw (93)–1
M8 x 20mm M8 x 50mm Bolt
M6 x 50mm Screw
Screw (65)–4 (70)–2
(89)–1
M10 x 98mm Screw (53)–4
